Home > Manufacturing & Processing Machinery > Lifting Equipment > Hoist > Manual Hoist

Manual Hoist

Name: Manual Hoist
Brand: Kuang Yuan
SKU: 102806517
Availability: InStock

US$ 1,000 - 3,450 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Place of Origin:

Henan, China

Brand Name:

Kuang Yuan

Contact Supplier Request Quote Chat Now

HNKS Crane Co., Ltd. ZD Branch

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao/Tianjin/Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Place of Origin Henan, China

Brand Name Kuang Yuan

Usage Construction Hoist

Power Source Hand Chain

Sling Type Wire Rope

Maximum Lifting Weight 0.25t

Maximum Lifting Height 2.5m

Lift Speed 8/7/3.5/4 m/min

Certification GB/GOSTR/TUV/ISO

Warranty 12 months

After-sales Service Provided Engineers available to service machinery overseas

Product Description

Manual Hoist

Manual hoist is a kind of widely used and portable manual operating hoisting machine,especially widely used on no power and liquid homework. It is popular for hanging it in the load-bearing structures, steel beam, tripod, rod or the trailer. It can be used in machine installation, products lifting and loading (unloading) in industry,agriculture,construction and mineral production.It is suitable to be used in the open air and no electric power works.

Features of the manual hoist

1.Conforms to AS1418.2 standards.

2.Compact design

3.Higt eficiency
3.With Overload Limiting device
4.Long working time
5.High strength end stop with secondary end anchor for increased safety.
7.Brake lockout bearing for security of braking mechanism.

Model		HS-J 0.5	HS-J 1	HS-J 1.5	HS-J 2	HS-J 3	HS-J 5	HS-J 10	HS-J 20
Capacity(T)		0.5	1	1.5	2	3	5	10	20
Standard lift(M)		2.5	2.5	2.5	2.5	3	3	3	3
Running test load(T)		0.75	1.5	2.25	3	4.5	6.25	12.5	25
Headroom(drawn close up)H(MM)		271	400	453	420	620	704	720	1000
Load chain	Columns	1	1	1	2	2	2	4	8
	Dia(mm)	6	6	8	6	8	10	10	10
Effort required to lift max load(N)		221	304	343	314	343	382	392	392

Company Information

HNKS Crane Co., Ltd is one of top 3 crane manufacturers in China and engaged in the manufacture and sale of "Kuangyuan" brand electric hoists, single or double beam overhead cranes, gantry cranes, grab cranes, foundry cranes, anti-explosion cranes and related spare parts.

We have passed CE, GOST, SGS, OHSAS, ISO9001:2000 international quality control standard, ISO14001:1996 environment and ISO9001:2001 health and safety standard. We have a perfect quality-control system, a strict management system, strong production capabilities and advanced testing measures to ensure the high production and high quality.

certifications

Our Services

Service we can provide:

1.Payment terms is flexible,

2.Design the crane according to your technical request,

3.Delivery on time,

4.Our engineer can arrive to the installation site to help fixing the crane for you,

5.Diversity products,

6.Warranty:12 months

7. Full solution for the cranes, include production, installation, modification and maintenance

FAQ

1.How to affirm the working class
RE: According to the application, Running hour and Working Environment, we will offer the professional advise.

2. How to operate the crane?

RE: There are Handle Pendent, Remote Control and Cabin Control operational methods could be selected, even two or three methods could be combination. The operation method are depend on the working environment, traveling speed and your demands.

3. What kinds of safety device will be offered for the Overhead Crane or Gantry Crane?

RE: Overload Limiter, Limit Switch (Lifting and Traveling), Interlock protection device, Buffer, Overhaul cage, Rail clear plate, Protective cover, Bus Bar preventer plate, Anti-collision device, Main isolating switch, Emergency stop system, Motor overload protection, and so on.

4. Do you offer special sling for the crane?

RE: Yes, according to your demands and usage, we could offer special slings, such as Lift sling belt, Lift clamps, Grab, Magnet, Lifting Beam, C hook, and other devices.

contact
