C5240 conventional dobule column vertical lathe machine for sale
- 100 Set / Sets per Month
- Dalian/Tianjing/Shanghai/Qingdao China
- T/T L/C D/P D/A
Product Details
Condition: | New | Type: | Vertical | CNC or Not: | Normal |
Automatic Grade: | Manual | Max. Swing Diameter: | 4000mm | Place of Origin: | Liaoning, China |
Brand Name: | LFM | Model Number: | C5240 dobule column vertical lathe machine | Voltage: | Customer's Requirement |
Power(W): | 55/75kW | Dimension(L*W*H): | Depend | Weight: | 39~50tons |
Certification: | CE; ISO9001:2008; GB/T19001:2008 | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
C5240 conventional double column vertical lathe
1.I.D. & O.D. cylindrical turning,
2. end-facing,
3. I.D. & O.D. cone turning,
4. grooving,
5. boring, drilling, reaming, etc.
Such double column vertical lathe has following features:
1. double column vertical lathe;
2. with DRO and CE Certificate;
3. such vertical lathe is suitable for turning the ferrous, nonferrous metal and some kinds of non-metal materials with hard alloy, high capacity and high speed steel tools.
4.Main bodies of the machine are made of high rigid resin sand castings with thermal aging treatment. Steel parts are thermal refined.
5.The machine adopts a stable rigid structure and consists mainly of base, table, column, cross rail, tool head, hydraulic system and electric system. Cross rail moves up and down along guideways of the column.
Specifications | Unit | Parameter |
Max. turning diameter | mm | 4000 |
Max. working height | mm | 1600/2000/2500/3150 |
Max. weight of workpiece | T | Standard 10 Optional 30 |
Table diameter | mm | 2830/3200 |
Speed range of table | r/min | 2~63 |
Speed-step of table |
| 16 steps |
Max torque of table | KN.m | 63 |
Max cutting resistance of right tool post | KN | 32 |
Max. cutting resistance of left tool post | KN | 28 |
Travel of right tool post Horizontal | mm | 2150 |
Travel of right tool post Vertical | mm | 1000/1300/1500 |
Travel of left tool post (Horizontal) | mm | 2150 |
Travel of left tool post (Vertical) | mm | 1000/1300/1500 |
Feed range and speed-step of tool post | mm/min | 0.24~145 18 steps |
Rapid traveling speed of tool post | mm/min | 1550 |
Crossbeam fluctuation travel | mm | 1300/1700/2200 |
Crossbeam fluctuation speed | mm/min | 350 |
Moving degrees limit of tool post |
| ±30° |
Cutting section of the tool bar | mm | 40×50 |
Crossbeam fluctuation motor power (AC) | KW | 7.5/11 |
Cutting feed two-speed motor power of left feeding-box (AC) | KW | 1.3/1.8 |
Fast motor power | KW | 2.2 |
Power of main motor (AC) | KW | 55/75(max. weight of workpiece:30t) |
Weight of machine (t) | T | 39~52 |
kinds of colors for your choice/can be customized
