Engine Hood Insulation Paper Ceramic Fiber Paper Ceramic Wool for Auto Industry

Engine Hood Insulation Paper Ceramic Fiber Paper Ceramic Wool for Auto Industry thumbnail-1
Engine Hood Insulation Paper Ceramic Fiber Paper Ceramic Wool for Auto Industry thumbnail-2
Engine Hood Insulation Paper Ceramic Fiber Paper Ceramic Wool for Auto Industry thumbnail-3
Engine Hood Insulation Paper Ceramic Fiber Paper Ceramic Wool for Auto Industry thumbnail-4
Engine Hood Insulation Paper Ceramic Fiber Paper Ceramic Wool for Auto Industry thumbnail-5
Engine Hood Insulation Paper Ceramic Fiber Paper Ceramic Wool for Auto Industry thumbnail-6
Engine Hood Insulation Paper Ceramic Fiber Paper Ceramic Wool for Auto Industry photo-1
Engine Hood Insulation Paper Ceramic Fiber Paper Ceramic Wool for Auto Industry photo-2
Engine Hood Insulation Paper Ceramic Fiber Paper Ceramic Wool for Auto Industry photo-3
Engine Hood Insulation Paper Ceramic Fiber Paper Ceramic Wool for Auto Industry photo-4
Engine Hood Insulation Paper Ceramic Fiber Paper Ceramic Wool for Auto Industry photo-5
Engine Hood Insulation Paper Ceramic Fiber Paper Ceramic Wool for Auto Industry photo-6
Negotiable MOQ: 100 Rolls (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Application:
Refractory, High-temperature Insulation
Thickness:
0.5-7mm
Contact Supplier Request Quote Chat Now
Zibo Yao Xing Fire-Resistant And Heat-Preservation Material Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Thickness 0.5-7mm
Width 610/1220mm
Length 100000-12000mm
Grade HZ (High Zirconium)
Chemical Composition Al2O3≥38% ,ZrO2≥15%
Working Temperature 1350
Fiber Diameter 3μm
Thermal Conductivity 0.075
Shrinkage (1800℉, 3h) ≤3%
Brand Name YAOXING
Model Number YXTX-336







Product Description





DENSITY 200KG/M3 CERAMIC FIBER PAPER





Technical Index



Classification Temperature

1260

1400

Code

YXTX-236

YXTX-336

Shrinkage on Heating (%)

1000°C×24h≤-3

1350°C×24h≤-3

Theoretical

 Thermal

Conductivity

(W/m·k)

(200°Caverage)

(400°Caverage)

(600°Caverage)

0.075-0.085

0.115-0.121

0.165-0.175

Theoretical Density (kg/m3)

200±15

200±15

Specification (mm)

100000/12000×610/1220×0.5/7,

According to your requirements

Tensile Strength(MPa)

≥0.04

AL2O3(%)

45-46

38~47

ZrO2

-

15~17

AL2O3+SiO2(%)

≥97

—

AL2O3+SiO2+ZrO2(%)

—

≥99

Fe2O3(%)

≤1.0

≤0.2

K2O+Na2O(%)

≤0.5

≤0.2

Package

Plastic Bag Inside, Carton Outside

Quality Control System

ISO9001-2000, ISO14001-1996





Size:



1.0.5mmX610/1220mmX90meters



2.0.7mmX610/1220mmX80meters



3.1mm  X610/1220mmX60meters



4.2mm  X610/1220mmX30meters



5.3mm  X610/1220mmX20meters



6.4mm  X610/1220mmX15meters



7.5mm  X610/1220mmX12meters



Characteristic:



1.Low Heat Storage



2.Low Thermal Conductivity



3.Excellent Thermal Electrical Insulation



4.Excellent Machine-processed Capability



5.Excellent Broken Resistance



6.Excellent Flexibility



7.Low Shot Content



Application:



1.Industrial insulating ,sealing and protecting materials



2.Electric and thermal insulation materials for electric industry



3.Insulation materials for instrument-equipment



4.Insulating materials for motor industry



5.Filling materials for expansion slot



6.Insulating materials as the sinter resistance



7.Sealing gasket for molten metal



8.Fireproof materials
