Home > Products > Ceramic Fiber Paper > flame retardant paper heat insulation paper for exhausts fireproof paper
flame retardant paper heat insulation paper for exhausts fireproof paper
- 1000 Roll / Rolls per Month
- QINGDAO
- T/T
Product Details
Place of Origin: | Shandong, China | Thickness: | 0.5-7mm | ||
Width: | 610/1220mm | Length: | 100000-12000mm | Grade: | HZ (High Zirconium) |
Chemical Composition: | Al2O3≥38% ,ZrO2≥15% | Working Temperature: | 1350 | Fiber Diameter: | 3μm |
Thermal Conductivity: | 0.075 | Shrinkage (1800℉, 3h): | ≤3% | Brand Name: | YAOXING |
Model Number: | YXTX-336 |
Product Description
DENSITY 200KG/M3 CERAMIC FIBER PAPER
Technical Index
Classification Temperature | 1260 | 1400 | |
Code | YXTX-236 | YXTX-336 | |
Shrinkage on Heating (%) | 1000°C×24h≤-3 | 1350°C×24h≤-3 | |
Theoretical Thermal Conductivity (W/m·k) | (200°Caverage) (400°Caverage) (600°Caverage) | 0.075-0.085 0.115-0.121 0.165-0.175 | |
Theoretical Density (kg/m3) | 200±15 | 200±15 | |
Specification (mm) | 100000/12000×610/1220×0.5/7, According to your requirements | ||
Tensile Strength(MPa) | ≥0.04 | ||
AL2O3(%) | 45-46 | 38~47 | |
ZrO2 | - | 15~17 | |
AL2O3+SiO2(%) | ≥97 | — | |
AL2O3+SiO2+ZrO2(%) | — | ≥99 | |
Fe2O3(%) | ≤1.0 | ≤0.2 | |
K2O+Na2O(%) | ≤0.5 | ≤0.2 | |
Package | Plastic Bag Inside, Carton Outside | ||
Quality Control System | ISO9001-2000, ISO14001-1996 |
Size:
0.5mmX610/1220mmX90meters
0.7mmX610/1220mmX80meters
1mm X610/1220mmX60meters
2mm X610/1220mmX30meters
3mm X610/1220mmX20meters
4mm X610/1220mmX15meters
5mm X610/1220mmX12meters
Characteristic:
1.Low Heat Storage
2.Low Thermal Conductivity
3.Excellent Thermal Electrical Insulation
4.Excellent Machine-processed Capability
5.Excellent Broken Resistance
6.Excellent Flexibility
7.Low Shot Content
Application:
1.Industrial insulating ,sealing and protecting materials
2.Electric and thermal insulation materials for electric industry
3.Insulation materials for instrument-equipment
4.Insulating materials for motor industry
5.Filling materials for expansion slot
6.Insulating materials as the sinter resistance
7.Sealing gasket for molten metal
8.Fireproof materials
