Ceramic Fiber Board for Glass Tempering Furnace Insulation 50mm Thickness

Ceramic Fiber Board for Glass Tempering Furnace Insulation 50mm Thickness thumbnail-1
Ceramic Fiber Board for Glass Tempering Furnace Insulation 50mm Thickness thumbnail-2
Ceramic Fiber Board for Glass Tempering Furnace Insulation 50mm Thickness thumbnail-3
Ceramic Fiber Board for Glass Tempering Furnace Insulation 50mm Thickness thumbnail-4
Ceramic Fiber Board for Glass Tempering Furnace Insulation 50mm Thickness thumbnail-5
Ceramic Fiber Board for Glass Tempering Furnace Insulation 50mm Thickness thumbnail-6
Ceramic Fiber Board for Glass Tempering Furnace Insulation 50mm Thickness photo-1
Ceramic Fiber Board for Glass Tempering Furnace Insulation 50mm Thickness photo-2
Ceramic Fiber Board for Glass Tempering Furnace Insulation 50mm Thickness photo-3
Ceramic Fiber Board for Glass Tempering Furnace Insulation 50mm Thickness photo-4
Ceramic Fiber Board for Glass Tempering Furnace Insulation 50mm Thickness photo-5
Ceramic Fiber Board for Glass Tempering Furnace Insulation 50mm Thickness photo-6
US$ 60 - 60 MOQ: 25 Pieces
Key Specifications
Get Latest Price
Brand Name:
Lever
Place of Origin:
China
Length:
1200mm
Contact Supplier Request Quote Chat Now
Luoyang Lever Industry Co.,Ltd
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Lever
Place of Origin China
Length 1200mm
Thickness 50mm
Grade HA (High Aluminum)
Width 1000mm
Application Heat Insulation
Chemical Composition AL2O3 43%, SIO2 53%
Working Temperature 1260
Thermal Conductivity 0.07(400℃) 0.09 (600℃) 0.12 (800℃)
Product Description
Heat resistant insulation material for glass tempering furnace inside use
Application:
As the filling materials in the heating oven for heat preservation
Material: High aluminum plate as hard type for surface layers
Ceramic fiber as soft type for inner layers
Classification temperature: 1260℃; 1360℃; 1430℃; 1600℃; 1700℃
Specification: as machine manufacturer
Grade
Standard
High Aluminium
Zirconium
Max Temperature (℃)
1260
1360
1430
Working Temperature (℃)
≤1150
≤1260
≤1350
Color
pure white
pure white
pure white
Density(Kg/m3)
170-220
170-220
170-220
Thermal conductivity(w/m.k)
0.07(400℃)
0.09 (600℃)
0.12 (800℃)
0.069 (400℃)
0.088 (600℃)
0.110 (800℃)
0.068 (400℃)
0.087 (600℃)
0.10 (800℃)
Comlression Strength (Mpa)
0.65
0.70
0.75
Chemical
composition(%)
AL2O3
42-43
51-52
39-40
SIO2
53
44
44
ZrO2
---
---
15-17
Fe2O3+Ti2O3
≤1.2
≤0.3
≤0.2
Na2O+k2O
≤0.5
≤0.3
≤0.2
CaO+MgO
≤0.3
≤0.3
≤0.2
Sizes(mm)
L*W*T
120,000*610/1220*0.5 60,000*610/1220*1
30,000*610*1220*2 20,000*610*1220*3
15,000*610/1220*4 12,000*610/1220*5
1,000*610*1220*6 6,000*60/1220*10
Product packaging
Packed in carton box
Quantities: 25 pieces
Each piece size:1200*1000*50mm
