Catalogue of XH6330 Series Universal Vertical and Horizontal Milling Machine
US$ 11,500 - 17,700
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Liaoning, China
Brand Name:
LFM
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
X6323B CE Vertical Turret Milling MachineUS$ 5,374 - 7,971MOQ: 1 Set -
S Series CE Bed Type Cnc Vertical Milling MachineUS$ 27,580 - 53,971MOQ: 1 Set
-
Catalogue of CE Cconomic Knee Type Vertical Milling MachineUS$ 5,074 - 30,971MOQ: 1 Set
-
Catalogue of Vertical Turret Milling Machine for SaleUS$ 3,500 - 13,500MOQ: 1 Set
-
XN6330h Universal Vertical and Horizontal Milling MachineUS$ 17,500 - 17,600MOQ: 1 Set
Condition
New
Place of Origin
Liaoning, China
Brand Name
LFM
Model Number
universal vertical and horizontal milling machine
Type
Universal
CNC or Not
Normal
Voltage
220V/380V/415V/440V/480V
Power(W)
5HP
Dimension(L*W*H)
1800x1500x2200mm
Weight
1900kgs
Certification
CE; ISO9001:2008; GB/T19001:2008
Warranty
12 months
After-sales Service Provided
Engineers available to service machinery overseas
X6330h universal vertical and horizontal milling machine
Main Features
xn6330h cnc universal vertical and horizontal milling machine has following features:
1. Super width of bed and keen box guide way, which have been hardened and precision ground,
2. with high rigidity and stability;
3. The guide way of the saddle is lined with TF wearable belt.
4. The machine with one vertical and horizontal spindle, the spindles and gears been hardened and ground, accuracy stable good, suitable heavy cutting.
5. Taiwan head & 3 axes Taiwan leadscrew.
Main Technical Data
| item | Unit | XN6330H | X6330H | XS6330H universal vertical and horizontal milling machine | |||
| Table size | mm | 300*1300 | 300*1300 | 300*1500 | 300*1370 | 300*1500 | |
| Table longitudinal travel (manual) | mm | 845 | 845 | 1000 | 880 | 1000 | |
| Table cross travel (manual) | mm | 385 | 380 | ||||
| Knee vertical travel (manual) | mm | 435 | |||||
| Table longitudinal feed rate | mm/min | 0-3500 servo motor | ------------ | ||||
| Table cross feed rate | mm/min | ------------ | |||||
| Knee rapid speed | mm/min | 900 | |||||
| vertical spindle | Motor power | hp | 5hp | standard:3hp optional:5hp | |||
| Speed | rpm | standard: 16 steps: 50HZ:65-4500,60HZ:80-5440 Optional: variable speed:65-3750 | |||||
| Taper | ISO40 | standard:R8 optional:ISO40 | |||||
| Quill travel | mm | 127 | |||||
| Quill feed | mm/rev | 0.04/0.08/0.15 | |||||
| Head rotating | R/L 90° | R/L 90° B/F 45° | |||||
| Distance from spindle end to table surface | mm | 115-545 | |||||
| Horizontal spindle | Motor power | hp | 5hp | ||||
| Speed | rpm | 50HZ:45/80/165/260/500/980 60HZ:55/100/200/315/600/1180 | |||||
| Taper | ISO40 | ||||||
| Distance from spindle end to table surface | mm | -430 | |||||
| Distance from spindle center to ram | mm | 183 | |||||
| Ram travel | mm | 480 | |||||
| Ram rotating | 360° | ||||||
| Net weight | kg | 1900 | 1900 | 1950 | 1680 | 1730 | |
| Package size LxWxH | mm | 1800x1500x2200 | 1800x1800x2200 | 1800x1600x2200 | 1800x1800x2200 | ||
Free Std Accessories
1. Drawbar
2. Working lamp
3. Electrical box
4. Handle oil pump
5. Tool and tool box
6. Cooling device
7. Workbench shield
8. Oil drip pan
