X6323 vertical turret milling machine
are widely used for processing flat face, slope face, keyway, key groove, slot and drilling, reaming, boring.
- Rectangular guide way on Y-and Z-axis is featured a good rigidity and stability.
- The guide way on saddle is lined with TF wearable material.
1. The milling head can turn 90°each side;
2. Ram can be turned 180° horizontally;
3.Spindle speed range is wide ranged and higher speed.
4.The spindle sleeve feeding can be set.
5.It is equipped with over load protection device.
6.Spindle sleeve and guide way is high frequency quenching.
7.Our milling machine is good looking and practical.
8. with CE;
Specifications |
Unit |
Parameter |
Table size |
mm |
230×1067 230×1246 |
Longitudinal travel |
mm |
650 840 |
Cross travel |
mm |
305 |
Vertical travel |
mm |
400 |
T-slot no and size |
mm |
3×16 |
Ram travel |
mm |
312 |
Distance from spindle to table surface |
mm |
0~415 |
Spindle hole taper |
|
Standard: R8 Optional: ISO30/ISO40 |
Spindletravel |
mm |
127 |
Spindlespeed |
rpm |
Standard: 16 gears:50Hz65~4500/60Hz 80~5440 |
|
|
Optional: Stepless speed 65~3750 |
Auto. quill feed |
rpm |
3 gears 0.04(0.0015)/0.08(0.003)/0.15(0.006) |
Spindle motor |
kW |
2.25 3hp |
Head swivel |
|
90° |
Head tilting |
|
45° |
size of package |
mm |
1400×1476×2030 |
Weight |
Kg |
1100 |
