XN6330H CE Vertical Turret Milling Machine for Sale

US$ 11,000 - 13,500 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Place of Origin:

Liaoning, China

Brand Name:

LFM

Contact Supplier Request Quote Chat Now

Long Life Machinery Import And Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Dalian/Qingdao China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Place of Origin Liaoning, China

Brand Name LFM

Model Number XN6330H XN6330H XN6330H turret milling machine

Type Vertical

CNC or Not Normal

Voltage 3Ph/220V 380V 400V 415V 440V 480V 50/60Hz

Power(W) 5HP

Dimension(L*W*H) 1800x1800x2200mm

Weight 1900kgs

Certification ISO9001:2008&CE

Warranty 12 Months

After-sales Service Provided Engineers available to service machinery overseas

X6330 vertical turret milling machine

Characters

Rectangular guide way on Y-and Z-axis is featured a good rigidity and stability.
The guide way on saddle is lined with TF wearable material.

Main Featurers

1. The milling head can turn 90°each side;

2. Ram can be turned 180° horizontally;

3.Spindle speed range is wide ranged and higher speed.

4.The spindle sleeve feeding can be set.

5.It is equipped with over load protection device.

6.Spindle sleeve and guide way is high frequency quenching.

7.Our milling machine is good looking and practical.

8. with CE;

Main Usage

are widely used for processing flat face, slope face, keyway, key groove, slot and drilling, reaming, boring.

Main Technical Data

model		unit	XN6330H	XN6330H		XN6330H
Table size		mm	300*1300	300*1300	300*1500	300*1370	300*1500
Table longitudinl travel (manual)		mm	845	845	1000	880	1000
Table cross travel(manual)		mm	385			380
Knee vertical travel(manual)		mm	435
Table longitudinal feed rote		mm/min	0~3500 Servo motor	------------
Table cross feed rate		mm/min		------------
Knee rapid speed		mm/min	900
Vertical spindle	Spindle motor	HP	5HP			Standard:3HP Optional:5HP
	Spindle speed	rpm	Standard:16 steps 50Hz:65~4500 60Hz:80~5440 optional:variable seed 65~3750
	Spindle taper		ISO40			Standard:R8 Optional:ISO40
	Quill travel	mm	127
	Quill feed	mm/rev	0.04/0.08/0.15
	Head rotating		Left 90°			Left 90° front and rear 45°
	Distance from spindle to table surface	mm	115~545
Horizontal spindle	Motor power	hp	5HP
	Spindle speed	rpm	50Hz:45/80/165/260/500/980 60Hz:55/100/200/315/600/1180
	Spindle taper		ISO40
	Distance from spindle to center to table surface	mm	-20~410
	Distance from spindle center to arm	mm	183
Arm travel		mm	480
Arm rotating			360°
Net weith		kg	1900		1950	1680	1730
LWH		cm	180150220		180180220	180160220	180180220
