Help CenterX50/61 Series Economic Universal Milling Machine for Sale Quality Choice
Related Products
-
X6330 CE Vertical Turret Milling MachineUS$ 8,940 - 9,636MOQ: 1 Set -
XN6330H CE Vertical Turret Milling Machine for SaleUS$ 11,000 - 13,500MOQ: 1 Set
-
CE Vertica & Horizontal Milling MachineUS$ 11,000 - 20,000MOQ: 1 Set
-
LVC Series CE Cnc Vertical Machning Center for SaleUS$ 30,174 - 75,000MOQ: 1 Set
-
XD40 CE Simple Cnc Vertical Milling Machine for SaleUS$ 27,580 - 31,971MOQ: 1 Set
CE universal milling machine Technical Data
1. We have many kinds of milling machines: vertical milling machine, horizontal milling machine, turret milling machine, CNC milling machine and others.
2. CE standard and CE Certificate;
Specifications |
Unit |
X5025 |
X5028 |
X5032 |
X5032B |
XL5032 |
XL5032C |
XL5032CL |
X5040 |
Table size |
mm |
250×1250 |
280×1200 |
320×1325 |
320×1600 |
320×1325 |
320×1325 |
320 x 1600 |
400 x 1700 |
Table Travel (X/Y/Z) |
mm |
680/280/400 |
620/280/400 |
700/680 255/240 370/350 |
900/880 255/240 370/350 |
750/320/460 |
1100/320/450 |
1300/320/450 |
1400/400/515 |
Table feed (X/Y/Z) |
mm/min |
20~800/20~800/10~400 |
20~800/20~800 /10~400 |
23.5~1180/23.5~1180/8~394 |
23.5~1180/23.5~1180/8~394 |
30~1200/20~800/15~600 |
30~1200/20~800/15~600 |
30~1200/20~800/15~600 |
30~1200/20~800/15~600 |
Spindle travel |
mm |
70 |
70 |
70 |
70 |
70 |
70 |
70 |
85 |
Spindle bore |
mm |
29 |
29 |
29 |
29 |
29 |
29 |
29 |
29 |
Spindle taper |
|
7:24 ISO50 |
7:24 ISO50 |
7:24 ISO50 |
7:24 ISO50 |
7:24 ISO50 |
7:24 ISO50 |
7:24 ISO50 |
7:24 ISO50 |
Rapid speed of table(X /Y/Z) |
mm/min |
1000/1000/500 |
1000/1000/500 |
2300/1540/770 |
2300/1540/770 |
2300/1540/770 |
2300/1540/770 |
2300/1540/770 |
2300/1540/770 |
T-slots (No./width/pitch) |
mm |
3/14/63 |
5/14/50 |
3/18/70 |
3/18/70 |
3/18/70 |
3/18/70 |
3/18/70 |
3/18/70 |
Distance between spindle nose and table |
mm |
35~435 |
35~435 |
60~410 |
60~410 |
50~510 |
50~500 |
50~500 |
30~500 |
Horizontal Milling Machine
Specifications |
Unit |
X6025 |
X6125 |
X6025A |
X6125A |
X6132 |
X6132B |
X6132H |
X6132BH |
XL6032 |
X6140 |
Table size (width × length) |
mm |
1250 x 250 |
1250 x 250 |
1250 x 280 |
1250 x 280 |
320 x 1325 |
320 x 1600 |
320 x 1325 |
320 x 1600 |
320 x 1325 |
1600 x 400 |
Longitudinal travel (manual/automatic) |
mm |
680 |
680 |
620 |
620 |
700/680 |
900/880 |
700/680 |
900/880 |
750 |
900/800 |
Max. transverse travel (manual/automatic) |
mm |
280 |
280 |
280 |
280 |
255/240 |
255/240 |
255/240 |
255/240 |
320 |
315/300 |
Max. vertical travel (manual/automatic) |
mm |
400 |
400 |
400 |
400 |
320/300 |
320/300 |
410/390 |
410/390 |
460 |
380/360 |
Max. rotary angle |
±45° |
±45° |
±45° |
±45° |
±45° |
±45° |
±45° |
±45° |
±45° |
±45° |
|
Distance between spindle and table |
mm |
75~475 |
35~435 |
75~475 |
35~435 |
30~350 |
30~350 |
30~440 |
30~440 |
20~480 |
20~480 |
T-slots ( No./ width/ pitch) |
|
3/14/63 |
3/14/63 |
5/14/50 |
5/14/50 |
3/18/70 |
3/18/70 |
3/18/70 |
3/18/70 |
3/18/70 |
3/18/70 |
|
Distance between spindle axis and ram surface |
mm |
155 |
155 |
155 |
155 |
|
|
|
|
175 |
30~410 |
Spindle taper |
7:24 ISO40 |
7:24 ISO40 |
7:24 ISO40 |
7:24 ISO40 |
7:24 ISO50 |
7:24 ISO50 |
7:24 ISO50 |
7:24 ISO50 |
7:24 ISO50 |
7:24 ISO50 |
|
Rapid speed of table (X/Y/Z) |
mm/min |
1000/1000/500 |
1000/1000/500 |
1000/1000/500 |
1000/1000/500 |
|
|
|
|
|
|
Table feed (X/Y/Z) |
mm/min |
(8)20~800/20~800 / 10~400 |
(8)20~800/20~800 / 10~400 |
(8)20~800/20~800 / 10~400 |
(8)20~800/20~800 / 10~400 |
|
|
|
|
|
2300/2300/ 770 |
Spindle speed range |
12 steps |
12 steps |
12 steps |
12 steps |
18 steps |
12 steps |
18 steps |
18 steps |
12 steps |
18 steps |
|
Spindle speed |
rpm |
35~1500 |
35~1500 |
35~1500 |
35~1500 |
30~1500 |
30~1500 |
30~1500 |
30~1500 |
60~1800 |
30~1500 |
Main motor power |
KW |
3 |
3 |
3 |
3 |
7.5 |
7.5 |
7.5 |
7.5 |
5.5 |
11 |
Rapid motor power |
KW |
0.75 |
0.75 |
0.75 |
0.75 |
1.5 |
1.5 |
1.5 |
1.5 |
1.5 |
1.5 |
Overall size (LxWxH) |
cm |
168 x 168 x 181 |
168 x 168 x 181 |
163 x 168 x 181 |
164x 168 x 181 |
229 x 177 x 161 |
229 x 205 x 161 |
229 x 177 x 179 |
229 x 205 x 179 |
180 x 210 x 187 |
255 x 215×177 |
N.W/G.W |
kg |
1300 |
1350 |
1350 |
1400 |
2650/2950 |
2740/3040 |
2850/3150 |
2740/3240 |
2400 |
3850 |
Turret Milling Machine
1, Your inquiry will be replied in 24 hours;
2, Our manufacture/company has been a Gold supplier continuously in this Alibaba website for 6 years. And there is more industry technology experience for 24years with our manufactures;
3, To offer free spare parts and service within one year of warranty;
4, Technical Support Provide operation video for training;
5, Professional after-sales service team;
Call us at any time: +86 -15641121240/15641121140
Fax us:+86-411-84410129
Payment Term:
- 30% down payment, 70% by T/T before shipment;
- 100% LC at sight(optional and shall be discussed before placing order);
Delivery Time:
- Normally, 30~60 days, however, different sizes of machines, delivery time will be different, pls consult for exact machine.
Minimum Order Quantity:
- 1 Set;
- ≥2 sets, there will be much discounts.
Warranty:
- Normally, 12 months for parts as of delivery of the machines;
Shipment:
- For machine itself, by sea or train(inland countries).
- For documents, by international express. eg DHL, TNT or EMS.
