CW62100Ex5000 manual horizontal gap lathe machine
Such manual horizontal gap lathe machine has following features:
- Standard: spindle head: C11/D11, spindle bore diameter: Φ100/105mm.
- Optional: spindle head: D11, spindle bore diameter Φ130mm.
- Guide rail width: 550mm.
- Guide way hardness: HRC50, Depth1.5mm.
- Max load weight between 2-centers: 1000kg; with steady rest: up to 2000kg.
- Standard: Left-hand wheel is equipped;
- Right-handed wheel shall be informed specially when placing order.
- Equipped with hydraulic clutch and electrical cabinet.
- Slide board boxes with vertical and horizontal rapid shift handle.
- Special indication is required if tailstock sleeve is with a scale.
CW62100Ex5000 manual horizontal gap lathe machine's technical information
Specifications |
Unit |
Parameter |
Max. swing over bed |
mm |
1000 |
Max. swing over carriage |
mm |
720 |
Center distance |
mm |
5000 |
Width of gap |
mm |
320 |
Swing over gap |
mm |
1230 |
Width of guide way |
mm |
550 |
Spindle bore diameter |
mm |
105/130 opt |
spindle nose |
|
C11/D11 opt |
Spindle speed |
rpm |
(18 speeds) 7.5~1000 |
Longitudinal feed |
mm/r |
(64) 0.1~24.3 |
Cross feed |
mm/r |
(64) 0.05~12.15 |
Rapid traverse speed |
m/min |
3.8 |
Metric thread |
mm |
(39)1~240 |
Inch thread |
TPI |
(26) 14~1 |
Module thread |
mm |
(53) 0.5~120 |
Diametrical pitch thread |
D.P |
(24) 28~1 |
Max. travel of cross slide |
mm |
493 |
Travel of top slide |
mm |
200 |
Main motor power |
kW |
11 |
Rapid traverse motor power |
kW |
1.1 |
Coolant pump motor power |
kW |
0.09 |
Wooden box/Pallet packing |
mm |
7600×1150×2080 7350×1100×1920 |
Gross/Net weight |
kg |
8900/6750 |
Name |
Size(mm) |
3-jaw chuck |
Φ400(For CW62100E) |
4-jaw chuck |
Φ630(For CW62100E) |
Steady rest |
Φ150~Φ400(For CW62100E) |
Follow rest |
Φ20~Φ160(For CW62100E) |
Dead center |
2 sets |
Reducing sleeve |
1 set |
Wrench Tool |
1 set |
Oil gun |
1 set |
Instruction Manual |
1 set |
Certificate of Conformity |
1 set |
Packing List |
1 set |
