Help CenterCDL6251 High-speed Bench Lathe for Light Machining
Related Products
-
Large Spindle Bore 130mm Universal Horizontal Lathe With GAP Hot-sale CW6280EUS$ 14,500 - 32,230MOQ: 1 Set -
CDS6276B/Cx2000 CE Universal Horizontal Lathe PriceUS$ 10,516 - 10,716MOQ: 1 Set
-
CW62100Ex3000 Universal Horizontal GAP LatheUS$ 19,900 - 21,221MOQ: 1 Set
-
CDE6240 Series Conventional Horizontal Lathe at Lower PriceUS$ 5,253 - 7,598MOQ: 1 Set
-
Catalogue of CW-E Series Horizontal Lathe With 105/130mm Large Spindle BoreUS$ 12,130 - 30,880MOQ: 1 Set
CDL6251 Mnual Lathe Technical Data
- Standard: spindle head is C6, Spindle hole: Φ48 mm
- Spindle head is D6, spindle hole: Φ52 mm;
- Guide rail width:300mm;
- Guide rail hardness:HRC50, Depth1.5mm;
- Hardened and ground guide ways;
- Maximum load capacity between two centers: 300kg
- Standard: the lathe is equipped with left-handed wheel;
- Right-handed wheel shall be informed specially when placing order;
- Three boxes are all self inside lubricating;
- Machine tool bed box are non-clutch;
- CE Certificated are not provided;
Specifications |
Unit |
Parameter |
Max swing over bed |
mm |
510 |
Max swing over carriage |
mm |
320 |
Center distance |
mm |
750/1000/1500 |
Max swing in gap |
mm |
735 |
Width of bed |
mm |
300 |
Spindle nose |
|
D8 |
Spindle bore |
mm |
82 |
Taper of spindle bore |
|
1:20(F 90) |
Spindle speeds |
rpm |
16~1600 (12 speed) |
Range of inch threads |
TPI |
2~56 |
Range of metric threads |
mm |
0.5~14 |
Range of module threads |
mm |
0.5~14 |
Range of Di metrical pitch thread |
D.P |
2~56 |
Longitudinal feed |
mm/rev |
0.06~0.82 (0.002"~0.032"/r) |
Cross feed |
mm/rev |
0.017~0.242 (0.007"~0.0095"/r) |
Lead screw diameter |
mm |
36 |
Pitch of lead screw |
mm |
6 |
Taper of tailstock quill |
|
M4 |
Travel of tailstock quill |
mm |
150 |
Diameter of tailstock quill |
mm |
60 |
Power of main motor |
kW |
5.5 |
Power of coolant motor |
W |
90 |
Net weight |
kg |
2040 |
Gross weight |
kg |
2585 |
|
WOODEN CASES STEEL PALLET (L×W×H) |
mm |
2430×1090×2000 2250×1100×1780 |
1, Your inquiry will be replied in 24 hours;
2, Our manufacture/company has been a Gold supplier continuously in this Alibaba website for 6 years. And there is more industry technology experience for 24years with our manufactures;
3, To offer free spare parts and service within one year of warranty;
4, Technical Support Provide operation video for training;
5, Professional after-sales service team;
Call us at any time: +86 -15641121240/15641121140
Fax us:+86-411-84410129
Payment Term:
- 30% down payment, 70% by T/T before shipment;
- 100% LC at sight(optional and shall be discussed before placing order);
Delivery Time:
- Normally, 30~60 days, however, different sizes of machines, delivery time will be different, pls consult for exact machine.
Minimum Order Quantity:
- 1 Set;
- ≥2 sets, there will be much discounts.
Warranty:
- Normally, 12 months for parts as of delivery of the machines;
Shipment:
- For machine itself, by sea or train(inland countries).
- For documents, by international express. eg DHL, TNT or EMS.
