CW6263x5000 conventional lathe machine for sale
- 100 Set / Sets per Month
- Dalian China
- T/T Credit Card PayPal
You May Like
-
CW62100Ex5000 manual horizontal gap lathe machine
-
CW61140Mx1000 heavy duty manual lathe machine
-
Catalogue of CW62100 universal horizontal lathe
-
CDL6251 High-speed Bench Lathe for Light Machining
-
Large Spindle Bore 130mm Universal Horizontal Lathe with GAP Hot-sale CW6280E
-
CDS6276B/Cx2000 CE universal horizontal lathe price
Product Details
| Condition | New | Type | Horizontal | |
| CNC or Not | Normal | Automatic Grade | Manual | |
| Max. Swing Diameter | 1000mm | Place of Origin | Liaoning, China | |
| Brand Name | DALIAN | Model Number | CW6263Ex5000 | |
| Voltage | 220V,380V,415V,440V,480V; 50/60Hz | Power(W) | 11/15kW; | |
| Dimension(L*W*H) | 7470x1100x1790mm | Weight | 6250kgs | |
| Certification | ISO9001:2008; GB/T19001:2008 | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Such conventional lathe has following features:
l Standard spindle head: C11, spindle bore Φ100mm,
l Optional spindle head: D11,spindle boreΦ130mm.
l Machine with hydraulic clutch and electrical cabinet
l Guide rail width:550mm
l Max load weight between 2-core clamper: 1000kg, with steady rest: up to 2000kg
l Order notice must be specified: condition of installed taper imitated shape device
l guide rail hardness:HRC50,Depth1.5mm
l Only provide the left-hand wheel.
l Slide board boxes with vertical and horizontal rapid shift handle included
l Tailstock sleeve with a dividing rule should be specially annotated;
Specifications | Unit | Parameter |
Max. swing over bed | mm | 630 |
Max. swing over carriage | mm | 350 |
Center distance | mm | 5000 |
Width of gap | mm | 320 |
Swing over gap | mm | 800 |
Width of guide way | mm | 550 |
Spindle bore diameter | mm | 105/130 opt |
spindle nose |
| C11/D11 opt |
Spindle speed | rpm | (18 speeds) 7.5~1000 |
Longitudinal feed | mm/r | (64) 0.1~24.3 |
Cross feed | mm/r | (64) 0.05~12.15 |
Rapid traverse speed | m/min | 3.8 |
Metric thread | mm | (39)1~240 |
Inch thread | TPI | (26) 14~1 |
Module thread | mm | (53) 0.5~120 |
Diametrical pitch thread | D.P | (24) 28~1 |
Max. travel of cross slide | mm | 493 |
Travel of top slide | mm | 200 |
Main motor power | kW | 11 |
Rapid traverse motor power | kW | 1.1 |
Coolant pump motor power | kW | 0.09 |
Wooden box | mm | 7600x1150x1890 |
Pallet packing | mm | 7470x1100x1790 |
Gross/Net weight | kg | 7950/6250 |
Name | Size(mm) |
3-jaw chuck | Φ320(For CW6263E) |
4-jaw chuck | Φ500(For CW6263E) |
Follow rest | Φ20~100(For CW6263E) |
Steady rest | Φ20~170(For CW6263E) |
Dead centers | M6 (2 deputy) |
Reducing sleeve | 1 set |
Wrench Tool | Yes |
Oil gun | Yes |
Foundationbolt | Yes |
Certificate of Conformity | 1 set |
Packing List | 1 set |
Instruction Manual | 1 set |
Manual for Spare Parts | 1 set |
