MA1420x2000 Universal Cylindrical Grinding Machine

US$ 47,500 - 48,364 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Cylindrical Grinding Machine

CNC or Not:

Normal

Long Life Machinery Import And Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Dalian/Shanghai China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Cylindrical Grinding Machine

CNC or Not Normal

Max. Grinding Diameter 200mm

Max. Grinding Length 2000mm

Place of Origin Liaoning, China

Brand Name LFM

Model Number M1420x2000 universal cylindrical grinding machine

Voltage 3Phx220V 380V 400V 415V 440V 480V, 50/60Hz

Power(W) 5.5kW

Dimension(L*W*H) 4900x1620x1500mm

Weight 7600kgs

Certification CE; ISO9001:2008; GB/T 19001:2008

After-sales Service Provided Engineers available to service machinery overseas

MA1420x2000 universal cylindrical grinding machine

Main Application

1. mainly used for grinding internal, external cylindrical and conical surface of parts.

2. It is ideal for single piece and small & medium-batch workshop.

Main Features

Such universal cylindrical grinding machine has following features:

1. Workpieces, internal and external grinding wheel, oil-pump, coolant pump are driven separately by their individual motors.

2. Worktable longitudinal traverse is actuated at infinitely variable speed by hydraulic means or by hand operation.

3. Wheelhead cross feed is provided with hyd.

4. Rapid approach & withdrawal, auto. Intermittent feed, manual feed.

5. CE Standard and CE Certificate;

Main Technical Data

Specifications		Unit	Parameter
Outside diameter grinding	Use Center Frame	mm	Min/Max: 8/60
Outside diameter grinding	No Center Frame	mm	Min/Max: 8/200
Inside diameter grinding	Use Center Frame	mm	Min/Max: 30/125
Inside diameter grinding	No Center Frame	mm	Min/Max:16/125
Max. Workpiece Weight		kg	150
Max. Grinding Length		mm	2000
Max. Grinding Diameter		mm	Φ200
Distance between centers		mm	2000
Height of center		mm	125
Motor total power		kW	7.455
Wheel Size ( diameter x width x bore )		mm	Min/Max Φ280 x 50 xΦ203 Φ400×50×Φ203
Wheel peripheral velocity		m/s	35/17.5
Wheel Spindle Speed		r/min	1680/840
Max. Transferred Quantity (Fast-moving Included)		mm	241
Rapid Advance and Retreat for Grinding Carriage		mm	25
Wheel Size (dia ×width×bore )		mm	Min: Φ15×20×Φ5 Max: Φ50×25×Φ13
Wheel Spindle Speed( HJX33-03A)		r/min	10000/15000
Machine Size (L×W×H)		mm	3900/4900×1620×1500
Packing Size (L×W×H)		mm	3880/4880×2250×2000
Gross/Net		kg	7600/8800
