SG2550 hydraulic surface grinding machine
Such manual surface grinding machine has following features:
3-axis manual operation
High rigidity H-frame column with spindle center to table
Enhanced ribbed full cast iron base
Roller steel balls on linear table ways for easy and smooth longitudinal movements.
CE Standard and CE Certificate;
Item/Model |
Unit |
SGA-2550AH SGA-2550AHR SGA-2550AHD |
Table size (W x L) |
mm |
250x500 |
Max. longitudinal travel |
mm |
560 |
Max. cross travel |
mm |
275 |
Max. distance from spindle center to table |
mm |
450 |
Electro magnetic chuck size |
mm |
250x500 |
Speed of table longitudinal movement |
mm/min |
7~23 |
Table transverse movement: Auto feed |
mm/min |
0.1~8 |
Table transverse movement: Rapid speed |
mm/min |
990 |
Table transverse movement: Feed of handwheel |
mm/div. |
0.02 |
Wheelhead vertical movement: Auto feed |
mm/min |
---[H/AH/AHR model] /0.005/0.01/0.02/0.03/0.04/0.05(Only for AHD model) |
Wheelhead vertical movement: Rapid speed |
mm/min |
---[H/AH model] /460(for AHR model) |
Wheelhead vertical movement: Feed of handwheel |
mm/div. |
0.005 |
Grinding wheel: Speed |
rpm |
2850(50Hz),3450(60Hz) |
Grinding wheel: Size(OD x W x ID) |
mm |
200x20x31.75 |
Spindle motor |
kW |
2.2 |
Hydraulic motor |
kW |
0.75 |
Cooling pump motor |
kW |
0.04 |
Elevating motor |
kW |
---(AH mode) 0.25(AHR mode) 0.5(AHD mode, servo motor) |
Cross feed motor |
kW |
0.04 |
Max. loading capacity of table (include chuck) |
kg |
180 |
Total rated power |
kW |
3.7 |
Height of machine |
mm |
1675 |
|
|
|
Floor space(L x W) |
mm |
2300x1600 |
Gross weight |
kg |
1800 |
Package dimensions(L x W x H) |
mm |
2000x2100x2175 |
Kinds of colors for your choice/can be Customized according to user's demand;
