M7150x1000 CE semi auto surface grinding machine
Such surface grinding machine has following features:
l It has higher accuracy and cutting efficiency.
l Vertical movable type wheelhead can load heavier workpiece than saddle type.
l The table in longitudinal movement driven by the vane pump, stability and low noise, easy opration.
l The temperature of oil pool is low and the precision is fit for National Standard (GB/T4022-1983).
l Grinding head has rapid movements mechanism invertical movement, but also manually feed.
l Grinding head vertical move can be adopted with power rapid movement or hand micro feed.
l Grinding head motor and pump motors are high-grade motor, electrical carry out the national safety standards.
l CE Standard and CE Certificate;
Pl, Accuracy of test piece among grinding center
Accuracy of long test piece
a)Circular degree: 0.002mm
Consistency for diameters: 0.005mm
P1, long test piece Ra 0.04μm
Short test piece Ra 0.01μm
P2, is Ra 0.02μm
P3, is Ra 0.04μm
Specifications |
Unit |
Parameter |
working area |
mm |
1000×500 |
Longitudinal table travel |
mm |
1140 |
Cross feed saddle travel |
mm |
540 |
Distance from spindle center to table |
mm |
750 |
Max. workpiece weight |
kg |
1000 |
T-slots |
mm×N |
16×3 |
Longitudinal table speed |
m/min |
5~25 |
Cross feed on hand wheel |
mm/gra. |
0.02 |
Cross feed on hand wheel |
mm/rev. |
5 |
Table rapid cross feed |
mm/min |
0.5~10 |
Table auto cross feed |
mm/min |
1250 |
Wheel dimension |
mm |
400×40×127 |
spindle speed |
rpm |
1450 |
Max. vertical movement |
mm |
700 |
Vertical on hand wheel |
mm/gra. |
0.005 |
Vertical on hand wheel |
mm/rev. |
0.25 |
Auto down feed increment |
mm |
0.002~0.04 |
Rapid elevating |
mm |
230 |
Down handwheel feed |
rpm |
1450 |
Spindle motor |
kW |
7.5 |
Vertical driving motor |
W |
180 |
Hydraulic motor |
kW |
3.75 |
Coolant motor |
W |
90 |
Cross feed motor |
W |
180 |
Machine height |
mm |
2400 |
Floor space |
mm |
2350×4500 |
Net weight |
kg |
5000 |
Gross weight |
kg |
6000 |
Packing size |
mm |
2850 *2250*2400 |
