Help CenterDL32Mx2000 CE Slant Bed Cnc Turning Lathe Machine for Sale
Related Products
-
CE Hot-sale CNC Slant Bed LatheUS$ 85,294 - 282,573MOQ: 1 Set -
DL20Mx600 China Inclined Cnc Lathe MachineUS$ 52,030 - 55,470MOQ: 1 Set
-
CE Slant Bed CNC Lathe With 12-station Turret Hot-sale DL30MUS$ 38,970 - 247,058MOQ: 1 Set
-
CE Economic Slant Bed CNC Lathe CL15 for Sales PromotionUS$ 39,653 - 51,470MOQ: 1 Set
-
DL32M Slant Bed CNC Lathe With CE for Sales PromationUS$ 105,271 - 151,429MOQ: 1 Set
1. Rigid cast-iron structure hardened (50-52HRC) and ground guarantee high precision and stability;
2. The machine bed is made of heat stabilized cast-iron;
3. A wide range of options and accessories allow the machine to be highly customized for very accurate and reliable machining;
4. Various configuration are available with spindles from ASA 5" to ASA 15",power up to 30kW and tuming length up to 3000mm;
Standard Configuration
5. 45° inclined bed split and box guide way;
6. spindle stepless speed;
7. 12-station hydraulic turret;
8. 15″ hydraulic Solid chuck and Hydraulic tailstock;
9. Lateral waste device and Closed-end protection;
Specifications |
Unit |
DL32Mx2000 slant bed cnc lathe |
Swing over bed |
mm |
Φ680 |
Center distance |
mm |
2000 |
Max. turning diameter(Shafts/ Discs) |
mm |
Φ400/630 |
Guide way type |
mm |
box-type |
Chuck size |
mm |
15" |
Spindle nose |
|
ISO A2-11 |
Spindle speed |
rpm |
20~2000 |
Main spindle motor power(S6) |
kW |
22(30) |
Spindle bore diameter |
mm |
Φ100 |
X-axis travel |
mm |
375 |
Z-axis travel |
mm |
1030 |
X-axis rapid traverse |
m/min |
13 |
Z-axis rapid traverse |
m/min |
13 |
Positioning accuracy |
mm |
(X)0.012(Z)0.025/0.03/0.04/0.05 |
Repeat positioning accuracy |
mm |
(X)0.007(Z)0.012/0.013/0.016/0.02 |
Turret: number of stations |
mm |
12 |
Tool size |
mm |
32×25 |
Tailstock quill diameter |
mm |
Φ160 |
Tailstock quill travel |
mm |
180 |
Tailstock taper |
MT |
5 |
Machine size: L×W×H |
mm |
6740×2040×2240 |
Net weight |
kg |
13000 |
