Technical Data
The new CL series of CNC slant bed lathes with rigid cast-iron structure hardened (50-52HRC) and ground guarantee high precision and stability. The machine bed is made of heat stabilized cast-iron.Varous configuration are available with spindles from ASA 5" to ASA 15",power up to 30kW and tuming length up to 3000mm,A wide range of options and accessories allow the machine to be highly customized for very accurate and reliable machining.
Standard Configuration
l 45°overall inclined bed, spindle Stepless Speed, 8″hydraulic solid chuck, 8-station hydraulic turret, Hydraulic tailstock, Lateral waste device, Closed-end protection, Linear guideway;
l CE Certificate is provided.
Item |
CL15 |
CL20A |
Swing over bed mm) |
400 |
440 |
Max turning length(mm) |
250/320 |
500 |
Max. turning diameter(Shafts)(mm) |
160 |
360 |
Max. turning diameter(Discs)(mm) |
200 |
300 |
Guide way type |
linear |
linear |
Chuck size |
6" |
8" |
Spindle nose |
ISO A2-5 |
ISO A2-6 |
Spindle speed (rpm) |
50~5000 |
45~4500 |
Main spindle motor power (S6)(kW) |
5.5(7.5) |
11(15) |
Spindle bore diameter (mm) |
46 |
62 |
Max bar diameter(mm) |
32 |
52 |
Positioning accuracy: |
X0.016mm Z0.020mm |
X0.016mm Z0.020mm |
Repeat positioning accuracy: |
X0.007mm Z0.008mm |
X0.007mm Z0.008mm |
X-axis travel (mm) |
120 |
165 |
Z-axis travel (mm) |
260/330 |
510 |
X-axis rapid traverse(m/min) |
15 |
15 |
Z-axis rapid traverse(m/min) |
18 |
20 |
Turret: number of stations |
8 |
8 |
Tool size (mm) |
20×20 |
25×25 |
Tailstock quill diameter(mm) |
60 |
80 |
Tailstock quill travel(mm) |
80 |
130 |
Tailstock taper(MT) |
3 |
3 |
Machine size: L×W×H(mm) |
2130/2350×1555×1880 |
2760×1500×1750 |
Net weight(kg) |
3300/3500 |
4800 |
CNC Type |
FANUC 0i-T |
FANUC 0i-T |
Fax:+86-0411-84410129
1, Your inquiry will be replied in 24 hours;
2, Our manufacture/company has been a Gold supplier continuously in this Alibaba website for 7 years. And there is more industry technology experience for 24years with our manufactures;
3, To offer free spare parts and service within one year of warranty;
4, Technical Support Provide operation video for training;
5, Professional after-sales service team;
Call us at any time: +86 -15641121240/15641121140
Fax us:+86-411-84410129
Payment Term:
- 30% down payment, 70% by T/T before shipment;
- 100% LC at sight(optional and shall be discussed before placing order);
Delivery Time:
- Normally, 30~60 days, however, different sizes of machines, delivery time will be different, pls consult for exact machine.
Minimum Order Quantity:
- 1 Set;
- ≥2 sets, there will be much discounts.
Warranty:
- Normally, 12 months for parts as of delivery of the machines;
Shipment:
- For machine itself, by sea or train(inland countries).
- For documents, by international express. eg DHL, TNT or EMS.
