High-speed Hot-sale TD500 Drilling And Tapping Center With CE

Name: High-speed Hot-sale TD500 Drilling And Tapping Center With CE
Brand: DALIAN
SKU: 102715419
Availability: InStock

US$ 37,500 - 51,470 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Vertical

Place of Origin:

Liaoning, China

Long Life Machinery Import And Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Dalian China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Vertical

Place of Origin Liaoning, China

Brand Name DALIAN

Model Number TD500A

Voltage 3Phx220V 380V 400V 415V 440V 480V, 50/60Hz

Power(W) 5.5kW

Certification CE Certificate; ISO9001:2008; GB/T19001:2008

Warranty 12 months

After-sales Service Provided Engineers available to service machinery overseas

CE Drilling And Milling Center Hot-sale TD500

Specifications	Unit	Parameter
Table size (L × W)	mm	650×400
Table load Max	kgs	300
X travel	mm	500
Y travel	mm	400
Z travel	mm	330
Distance from spindle center line to column guide way surface	mm	400
Distance from spindle nose end face to table upper surface	mm	150~480
X/Y/Z cutting speed	mm/min	0~20000
X/Y/Z rapid traverse speed	m/min	48/48/48
Spindle speed range	rpm	50~12000(20000 opt)
Spindle taper		No.30 (7:24 )
Spindle motor power	kW	5.5/3.7 (35/23.5Nm) Mitsubishi M70VA SJ-V5.5-01T
X/Y/Z servo motor power	kW	1.5/1.5/2.2
Tool magazine capacity / Type		16 T(swing)
Tool adaptor type		BT30
Max. Tool weight	kg	3
Max. Tool diameter/length	mm	Ø80/Ø200
Time of tool change (T-T)	sec	1.6

T-slot (Numbers × Width × Distance)	mm	3×14×125
Positioning accuracy(National Standard)	mm	X,Y,Z:0.010
Repeat positioning accuracy(National Standard)	mm	X,Y,Z:0.006
Air pressure requirement(Flow L/min)	MPa	0.5-0.7(200)
Overall dimension (L × W × H)	mm	2040×1580×2155
Net weight	kgs	2350
