Genew GAX7000 Series Enterprise series Smart Wireless LAN Controller
Genew patent CUBE technology enables GAX7000 WAC supporting flexible design and high performance network architecture for different types of WiFi system roll-out.
Single Chassis of GAX7000 support AC or DC redundant power supply unit, Dual Controller redundant slot can equip with 2 x Controller module for Hot-Standby configuration.
Optional interface module provides 10G backhaul line upgrade. It offer extreme high capacity and availability for advance and mission critical Enterprise WiFi system setup.
All GAX7000 series equip with ASIC base multi-core CPU in handling wireless data processing and forwarding.
Under the CUBE industry leading network system architecture, GAX7000 WAC can support Cloud base management of WiFi network, SON (Self Optimizing Network) function and features, modular plug-in different functional software modules.
WAC not only manage AP and the WiFi system, it also support large number of users device, including smartphone, Pad and notebook device connection, Fit AP management, 802.11n to 802.11ac AP traffic, seamless Layer2/3 roaming across the WiFi system, security authentication, WIDS, user profile policy base control, WiFi channel auto-selection, RF-power control, Load balancing control, local WAC mode, remote or Cloud base WAC mode in managing the WiFi network.
Product Highlight
Ø Central Cloud Management (CCM)
Ø Self-Optimizing Network (SON), Channel and RF management
Ø End-to-End Security
Ø RADIUS AAA and Portal Server
Ø Reliability and Redundancy
Ø Portal 1+1 redundancy
Ø DHCP Server Redundancy
Ø Seamless Roaming
Ø Smart Load Sharing
Item |
Sub-item |
Description |
Physical spec |
Dimensions(mm) |
440×380×178 |
|
Weight |
28kg (Full Configuration) |
|
Humidity |
10-90% condensation |
|
Operating Temperature |
0~40°C |
Interface spec |
Slot number |
3 |
|
10GBase-SR ports |
2(at Max) |
|
10/100/1000 Base-T Ethernet ports |
20(at Max) |
|
1000Base-X SFP ports |
20(at Max) |
Electrical spec |
1 +1 power redundancy |
1+1 |
|
Operating Voltage |
100~240 AC ; - 48V DC |
|
Operating Current |
50Hz/60Hz(±6Hz) |
Capacity spec |
Power consumption (full configuration) |
280W (Full Configuration) |
|
Number managed AP in centralized mode |
4096 |
|
Wireless users |
128K |
|
Throughput |
104Gbps |
|
3DES encryption performance |
20Gbps |
|
AES-CCM encryption performance |
20Gbps |
|
L2/L3 roaming switch time |
<50ms |
|
802.11 data processing performance |
20Gbps |
|
Host IP table |
64K |
Electromagnetic compatibility & safety |
Port based VLAN |
4094 |
Packaging:
1. All products will be packed in carton, so the product can get effective protection to avoid damage.
2. Packaging according to customer requirement
Shipping:
1. We shipping via DHL / FedEx / TNT etc for samll orders. Yow can get your packages in about 3-5 days all over the world.
2. For big order, we will arrange Air cargo for your shipment, so it will be much cheaper than DHL, UPS etc.
3. You can choose your own shipping agent, we will provide good cooperation for it.
1,We can provide detail documents and remote help for device installation and configuration.
2,Warranty: 1 year. ( After the quality guarantee period began to charge appropriate maintenance service fee.)
3,Our company promises goods enjoy full return due to quality problem since goods delivered within 7 days or 15 days , returned goods must keep original state and it’s accessories are complete.
