Genew GAH5000-EN2W Series Enterprise series Indoor Wireless Access Point
1. GENEW GAH5000-EN2W series wall ap----small box with full functions!
It supports for the 802.11n protocol, MIMO 2*2, up to 300Mbps access, supports for 5G terminal; besides, advanced features, such as: high compatibility, fast deployment, by working with GENEW controller to do the RF management, security, QoS, access control, flexible forwarding, etc.
2. This GAH5000-EN2W is well suitable and capable to provide good wireless coverage for hotel, dormitory, apartment, hospital wards or special clinic, government office, the places which are with thick walls, hard to do cable layout.
- Ø MIMO2*2 300Mbps high-speed wireless access
- Ø Full wireless coverage, supports for 5G terminals
- Ø Zero-interference to previous wired network
- Ø Small box, easy to deploy
- Ø Supports for the central authentication and local forwarding
Based on below 2 methods, GAH5000-EN2W can well cover the indoor area, details as shown:
· 2 spacial stream MIMO2*2 design
· 300Mbps high-speed access
· 5G access
· Zero-interference to wired network
· 7 designs easy the deployment
Item |
Function |
GAH5000-EN2W |
GAH5000-EN2W-AE |
HW Spec |
Ethernet port |
Front: 2*10/100M Base-T Ethernet port(RJ45) Back: 1*10/100MBase-T Ethernet (RJ45/cable clip)optional |
Front: 2*10/100M Base-T Ethernet port(RJ45) Back: 1*10/100/1000MBase-T Ethernet port(cable clip) |
|
Phone port |
Front: 1*RJ11,Back: one phone cable clip |
|
|
Performance |
300Mbps |
|
|
RF module |
1*802.11b/g/n module |
1*802.11a/b/g/n module |
|
Frequency |
2.4GHz-2.4835GHz |
2.4GHz-2.4835GHz /5.725-5.850GHZ (selective) |
|
Max. Tx power |
20dBm |
|
|
Adjustment step |
1dBm |
|
|
POE |
802.3af |
|
|
Power consumption |
≤7W |
|
|
Reset |
Y |
|
|
Status Indicator |
Power,Ethernet port, wireless |
|
|
Weight |
0.2KG |
|
|
Size(L*W*D) |
86mmX86mmX43mm |
|
|
Storage/working temperature |
-40℃~85℃/-10℃~55℃ |
|
|
Storage/working humidity |
5%~95%(non-condensing) |
|
|
Security spec |
GB4943-2000,UL 60950-1, EN 60950-1,IEC60950-1 |
|
|
EMC |
EN300 328,EN301 489,EN55024,CISPR22,EN61000 |
|
|
MTBF |
>80000h |
|
WLAN Basis |
SSID |
16 |
|
|
RTS/CTS |
Y |
|
|
WDS |
Y |
|
Packaging:
1. All products will be packed in carton, so the product can get effective protection to avoid damage.
2. Packaging according to customer requirement
Shipping:
1. We shipping via DHL / FedEx / TNT etc for samll orders. Yow can get your packages in about 3-5 days all over the world.
2. For big order, we will arrange Air cargo for your shipment, so it will be much cheaper than DHL, UPS etc.
3. You can choose your own shipping agent, we will provide good cooperation for it.
1,We can provide detail documents and remote help for device installation and configuration.
2,Warranty: 1 year. ( After the quality guarantee period began to charge appropriate maintenance service fee.)
3,Our company promises goods enjoy full return due to quality problem since goods delivered within 7 days or 15 days , returned goods must keep original state and it’s accessories are complete.
Genew Technologies Co., Ltd. designs, manufactures and sells telecommunications infrastructure, handsets and customer premise equipment and provide services associated with their installation, operation, and maintenance. Our portfolio also includes OEM/ODM services with world-class telecommunication partners such as Huawei, ZTE, Datang Mobile, UTStarcom, Nokia-Siemens Networks and Fiberhome.
While historically the vast majority of our sales have been to industrial clients involved in Mining, National Grid and Military in China, we have expanded our focus to build a global presence and currently sell our products in several other established and emerging growth markets, which include Japan, India, Latin America, EMEA and Asia.
Genew Technologies Co., Ltd.
Address: F3, Dazu Creative Building C, NO.9018,Beihuan Ave., Nanshan District, Shenzhen, China
Fax: +86-755-26619963
Attn: Helen Qiu
Trademanager: cn1517528120zlzr
Skype: helen.qiu001
Any request or query, please directly contact us.
