Most popular Yingfeng JZ280 solid clay brick machines for sale
We are a high-tech enterprise, integrating science, industry and trade for brick and tile machinery with our brand more than 30 varieties and over 100 specifications.Now we have built more than 2000 brick production line in China and abroad. Our main products:
Clay Brick Making Machine
Interlock Brick Making Machine
Cement Brick Making Machine
Tile Making Machine
What's the features of JZ280 solid clay brick machine?
JZ280 series Non-Vacuum solid brick making machine is the earliest and mature product.
It usually takes one motor.It is suitable to the following buyers:
1.Having limited electric power and very limited budget and not much demand for bricks amount
2.In buyers brick market, no much requirements on brick quality
3.Only wants to produce solid bricks (small hole brick is also possible if your raw material is fine enough for above
30 model extruder)
The difference between non-vacuum and vacuum extruder
1. Non-vacuum extruder usually can only produce solid bricks. . Vacuum brick is extruded out of the vacuum extruder.
And non- vacuum extruder has no extraction equipment, so the brick hardness is not so much as vacuum bricks.
2.Because the vacuum brick is first extracted with air and water , naturally shorter firing time, rapid proto typing. Greatly reducing the production cycle.
More technical parameters for your reference:
Type |
Capacity(pcs/h) |
Auger Diameter (mm) |
Extruding Pressure (Mpa) |
Extruder Power (KW) |
Whole production line power KW) |
JZ250 |
2000-3000 |
250mm |
0 |
11 |
15-47 |
JZ280 |
3000-4000 |
280mm |
0 |
22 |
50-70 |
JZ300 |
4000-6000 |
300mm |
0 |
30 |
70-80 |
JZ350 |
6000-7000 |
350mm |
0 |
40 |
80-95 |
JZ400 |
8000-10000 |
400mm |
0 |
55 |
120-140 |
JZ500 |
13000-16000 |
500mm |
0 |
90 |
150-180 |
Note: The above capacity is based on Chinese brick size : 240X115X53 mm, if your brick size is different from our brick size, then the capacity will differ .We would send different brick capacity list and different brick machine price list to you once we get your mail.
The following is part of brick sample which JZ280 Solid clay brick machine can produce .
Brick extruder |
Solid bricks Void ration ≤ 10% |
Perforated brick Void ration 15%~35% |
Hollow brick Void ration≥40% |
JZ Non-vacuum extruder |
√ |
× |
× |
DZK Single stage Vacuum extruder |
√ |
× |
× |
JKR Double stage Vacuum extruder |
√ |
√ |
√ |
JZK Double stage Vacuum extruder |
√ |
√ |
√ |
JKY Double stage Vacuum extruder |
√ |
√ |
√ |
Note: The above brick sampe is just for your reference, We can provide other different brick machine with different mould sizes according to your requirements.
JZ280 solid clay brick machine production line:
Note:The above production line is based on soft clay,mud,soil.If your material is shale,fly ash,coal Gangue,or with big stones,grass roots,etc,or you want to buy brick carrying cars or robot ,brick stacker, the above line will be adjusted after we get your feedback for your material condition.
JZ280 solid clay brick machine Delievery For Our Clients. Packing list:
| Item | Number |
| Brick exturder | 1 set |
| Box Feeder | 1 set |
| Double Roller Crusher | 1 set |
| Clay Shaft Mixer | 1 set |
| Brick Cutter | 1 set |
| Auto-board bearer | 1 set |
| Motor | 1 set |
| Belt conveyor | 2 set |
| V belt | 1 set |
| Mould | 1 set |
| Electric cabinet | 1 set |
| Secondary Control cabinet | 2 set |
| 2 years spare parts | 1 set |
| Brick factory Tools | 1 set |
| Warranty Card | 1 copy |
| Product Manual | 1 copy |
Note: The above packing list is based on standard clay brick production line, if your soil contains stones, grass root, then extra equipment need to be added. The final packing list will be changed according to buyer's final machine order
1.Each small part of machine would be packed well, also we would arrange engineer to check each machine parts before delivery, so we can ensure buyer can get complete clay brick machine parts. .
2. Some parts will be given soft protection before feeding in the container to make sure all the machine will
be new when arriving at customer hand.
3. Inside the container, we will fix the machine with steel wire,to make sure all the machine will be fixed safety.
Our solid brick making machine have been exported to countries such as India, Bangladesh ,Indonesia, Myanmar,Kazakhstan, Uzbekistan, Russia,Turkmenistan, Mongolia, Nepal, Sudan, South Africa,
Uganda, Mozambique, Zimbabwe,Congo,Peru, Brazil, Iraq ,Bolivia Mexico,etc. and have won great fame
and popularity..Below is part of our delivery photos for our clients from different countries.
Our JZ280 solid clay brick machine Service :
Aftersale service is an important part in our brick machine industry, after more than 20 years, we have much
more experience to support our buyer of brick machine.
2.Successfully running unit abroad for customer’s study and reference;
3.Manual book and videos are available on our offical website() after password provided;
4. Provide customers with various brick making equipments;
5. provide services like process design, kiln design, workshop design;
6. Also, we have a professional team of engineers to do clay brick machine installation, training workers,
imparting technical instruction to our buyers;
7. After brick machine running, we have special aftersale service department to provide spare parts, machine
problem fixing.
