Hydraulic Yoke Steel Scrap Melting Furnace by Complete Solution
Steel frame induction melting furnace
Application:
This Aluminum Shell Intermediate Frequency IElectrical Melting Furnace, also called as Induction Smelting Furnace is for melting cast steel, cast iron, stainless steel, copper, aluminum and other metals or its alloy.
Specification:
1. Turn on and turn off the smelter easily, and power failure will not affect the service life of electric furnace.
2. Adopt constant power to control the circuit, maintain constant power while melting, and keep faster melting rate.
3. Set up over voltage, over current and water deficient protector, and run safely.
4. The motherboard adopts CAD technology, integrated circuit board, low-fault-rate, easy-manipulating, effortless maintenance.
5. Zero voltage starts up softly, high initial power, don´t impact on the electric network.
6. Apply to melting ferrous metal and non-ferrous metal like copper, aluminum, zinc, steel, iron, stainless steel etc..

Technical Parameter:
model |
rated capacitykg |
input voltageV |
rated powerkw |
rated frequencyHz |
melt timemin/stove |
consume electricity (kw.h/t) |
consume water (M³/h) |
matched transformer (KVA) |
GW-0.15 | 150 | 380 | 100 | 1000 | 85 | 800 | 3 | 150 |
GW-025 | 250 | 380 | 160 | 1000 | 85 | 800 | 3 | 180 |
GW-0.5 | 500 | 380 | 250 | 1000 | 80 | 750 | 5 | 250 |
GW-1.0 | 1000 | 380 | 500 | 1000 | 75 | 750 | 8 | 500 |
GW-1.5 | 1500 | 380 | 750 | 1000 | 75 | 720 | 10 | 800 |
GW-2.0 | 2000 | 380/660 | 1000 | 500 | 75 | 700 | 12 | 1000 |
GW-3.0 | 3000 | 660 | 1500 | 500 | 75 | 700 | 16 | 1500 |




1, One year warranty service.
2, Sending professional engineer to installation,
debugging and training.
3, Provide video for teaching, installation instruction, and other
relevant technical documents.
4, We have more than 20 years experienced casting engineer to
solve any your problem.
