Steel Shell Magnet Yoke Melting Furnace
- 500 Set / Sets per Month
- Jiangmen China
- T/T Credit Card
Product Details
Condition: | New | Type: | Induction Furnace | Usage: | Melting Furnace |
Place of Origin: | Guangdong, China | Brand Name: | Xinxing | Model Number: | KGPS-GW series |
Warranty: | 12 months | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Steel Shell Magnet Yoke Melting Furnace
APPLICATION:
This kind of Medium Freqency Melting Furnace is for melting cast steel, cast iron, stainless steel, copper, aluminum and other metals or its alloy.
MF Electrical Furnace specification:
1. Turn on and turn off the smelter easily, and power failure will not affect the service life of electric furnace.
2. Adopt constant power to control the circuit, maintain constant power while melting, and keep faster melting rate.
3. Set up over voltage, over current and water deficient protector, and run safely.
4. The motherboard adopts CAD technology, integrated circuit board, low-fault-rate, easy-manipulating, effortless maintenance.
5. Zero voltage starts up softly, high initial power, don´t impact on the electric network.
6. Apply to melting ferrous metal and non-ferrous metal like copper, aluminum, zinc, steel, iron, stainless steel etc..
Technical Parameter:
model |
rated capacitykg |
input voltageV |
rated powerkw |
rated frequencyHz |
melt timemin/stove |
consume electricity (kw.h/t) |
consume water (M³/h) |
matched transformer (KVA) |
GW-0.15 | 150 | 380 | 100 | 1000 | 85 | 800 | 3 | 150 |
GW-025 | 250 | 380 | 160 | 1000 | 85 | 800 | 3 | 180 |
GW-0.5 | 500 | 380 | 250 | 1000 | 80 | 750 | 5 | 250 |
GW-1.0 | 1000 | 380 | 500 | 1000 | 75 | 750 | 8 | 500 |
GW-1.5 | 1500 | 380 | 750 | 1000 | 75 | 720 | 10 | 800 |
GW-2.0 | 2000 | 380/660 | 1000 | 500 | 75 | 700 | 12 | 1000 |
GW-3.0 | 3000 | 660 | 1500 | 500 | 75 | 700 | 16 | 1500 |
1, One year warranty service.
2, Sending professional engineer to installation,
debugging and training.
3, Provide video for teaching, installation instruction, and other
relevant technical documents.
4, We have more than 20 years experienced casting engineer to
solve any your problem.
