Automatic Pick and Place Machine/SMD LED Mounting Machine
US$ 1 - 40,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Chuangwei
Model Number:
CWTP-4H
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen/hongkong
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Semi-auto Pick and PlaceRobot Machine/SMD LED Mounting Machine With 6 HeadsUS$ 1 - 40,000MOQ: 1 Set -
4 Heads Automatic Pick and Place Machine/LED MounterUS$ 1 - 40,000MOQ: 1 Set
-
LED Manufacturing Pick and Place Machine/LED MounterUS$ 1 - 40,000MOQ: 1 Set
-
Floor Type Pick and Place Machine/LED Mounting MachineUS$ 1 - 40,000MOQ: 1 Set
-
LED Light Pick and Place Machine/LED MounterUS$ 1 - 40,000MOQ: 1 Set
Place of Origin
Guangdong, China
Brand Name
Chuangwei
Model Number
CWTP-4H
4 Heads Automatic Pick and Place Machine/LED Mounter
Specifications for Automatic Pick and Place Machine/SMD LED Mounting Machine:
| Maximum board size | 1200*300mm |
| Model | CWTP-4H |
| Max moving range | X: 1210mm, Y:330mm, Z:10mm |
| Typical mounting speed | 20000cph |
| Max mounting speed | 28000cph |
| Mounting accuracy | ±0.05mm |
| Position menthod | Visual position |
| Component | 0603 above SMD component & LED |
| Feeders | 8/12/16/24mm(Optional) |
| Nozzle | Juki 504/505/506 |
| Operation system | Windows XP |
| Compressed air | Vacuum air in machine |
| Power | 110-240V |
| Dimension | 2000*930*1450mm |
| Weight | 750kgs |
| Program method | Automaticdataimport/videostudy/keyboardinput |
Automatic Pick and Place Machine/SMD LED Mounting Machine local photos
Pick and place machine nozzle photos
Pick and place machine package : plywood case
