4 Heads Automatic Pick and Place Machine/LED Mounter
Specifications for 4 Heads Automatic Pick and Place Machine/LED Mounter :
| Maximum board size | 1200*300mm |
| Model | CWTP-4H |
| Max moving range | X: 1210mm, Y:330mm, Z:10mm |
| Typical mounting speed | 20000cph |
| Max mounting speed | 28000cph |
| Mounting accuracy | ±0.05mm |
| Position menthod | Visual position |
| Component | 0603 above SMD component & LED |
| Feeders | 8/12/16/24mm(Optional) |
| Nozzle | Juki 504/505/506 |
| Operation system | Windows XP |
| Compressed air | Vacuum air in machine |
| Power | 110-240V |
| Dimension | 2000*930*1450mm |
| Weight | 750kgs |
| Program method | Automaticdataimport/videostudy/keyboardinput |
Features for 4 Heads Automatic Pick and Place Machine/LED Mounter:
1) Theplatformtransmissionusestheimportedlinearguiderailandleadscrewin
combinationwiththeJapanoriginalPanasonicservodriveensuringthehigh-speed
stationarityandcontrolprecisionoftheplatform.
2) ThetransmissionoftheXandYshaftsusestheimportedhigh-precisiongroundlead
screwsandlinearguiderailsincombinationwiththeJapanPanasonicservodrive
ensuringthehighprecisionandhighspeedofmounting.
3) 4setsofhigh-speedmountingheadsworksimultaneously.Thesuckingheadsuse
high-precisiondurablesplineshafts.
4) Easyoperationalprogram,muchmoreconvenient,automaticvisionmakespositionfixin
gmoreaccurateandconvenient.
5) MultiFeederoptional,canmeetdifferentkindsofLEDmounting.
6) Powerfulsoftwareadoptsnumbersandimagestodisplaytheprogramcoordinate,easy
andmoreconvenient.
7) Softwareadoptsdatasystem,andstoredifferenttypesofPCBforconvenientadjustmen
t,justneedtoprogrammingonetimefornewproductstouseforever.
8) Platform:Yaxis,Xaxiscanbemovedmanually,speedadjustable,canachievearbitrary
pointmanualarrived,convenientprogramming.
9) LEDPick&PlaceMachineuseimportedvacuumdetectionsystem,itcancheckthesucti
onaccuratelytopreventmaterialleakageandthrowingeffectively.
10) Internalnegativepressuresystem:lownoise,longservicelifeandvacuumpressurecons
tant.
11) Standardsetting:1PC,4mountingheads,12nozzles.
12) Optinal:8mm,12mm,16mm24mmautomaticfeeder,differentnozzles,industrialpump,
aircompressor.
Pick and place machien local photos
Package : plywood case
