Specifications
iCON160 is a controller for Access control,Time Attendance,Entrance Billing Function,Alarm system or Industrial Automation.iCON160 is a Multifunctional controller for Access control, Time Attendance, Entrance Billing Function, Alarm system and Home or Industrial Automation.
It can control 1 door (double sided) or 2 doors (single sided) and alarm system with 4 zones. Capacity to store up to 16,400 users and 8200 events. There are 2 inputs for readers, 2 lines with alarm monitoring, line open and short, siren output for alarm monitoring, 6x inputs (exit button, smoke detector, etc..) and 1-W port for communication with DALLAS 1-W devices (temperature sensors, A / D converters, etc.). Ability to work with cards, cards + PIN and cards + work code. The setup can be performed using specialized software or controller keyboard.
Flexibility - provides network connectivity out of the box beside industry standard RS485 and RS 323 communication
Management - remotely managed over the network via standard web browser or over built in keyboard
Cost savings - access control, alarm system, TCP connection, power supply, 1-Wire bus all in one unit
Reliable - works independently of the server
Specialized multifuncional inteligent controller, integrating the management of an access control, alarm and automation system through a web server or server-client software.
Features:
- 1-2 Door Access Control panel with 2-4 zone alarm system
- Card holders 8100 or 16 400 depending of installation memory
- Event Buffers 4100 or 8 200 depending of installation memory
- Standalone or Network communication via RS485 (Max. 253ch), RS232, LAN
- Built in 2x Wiegand readers input with auto sense function
- Reader interface: 26 or 32 bit WIEGAND (auto detect) and 4-8 bit burst for PIN
- Working mode of the readers: RFID card, PIN, RFID card and PIN, RFID card or PIN, RFID card with PIN, and RFID card with Working code
- Built in 1-W port to communication with DALLAS 1-W devices (i-buttons, Temperature sensor, RH sensor, A/D converter or etc.)
- Built in 2x inputs for Door contact
- Built in 2x inputs for Exit buttons
- Built in Emergency input
- Built in 2 lines for Alarm zones with short and open detection
- Built in Multi purpose Analog input 0..10V
- Built in 6 relay outputs(125V/3A), including Siren detection
- Built in Multi purpose 2x outputs open collector 30V/0.5A
- Power: 230VAC, build in AC/DC SMPS
- Battery charger with Low voltage protection (battery disconnect)
- 12VDC out with over current & short current protection
- Built in Web Server for remote monitoring and management
- Supports TCP/IP, ARP, DHCP client, TCP client, TCP Server, Ping
- Weekly Time table
- ICON160 can be used as Converter RS485 to Ethernet
- The setup can be performed using specialized software (Andromeda-paid or free) or controller’s keyboard.
APPLICATIONS
Access Control - To control and restrict physical access to certain areas, sites and buildings. Systems for access control are widely used in small offices, commercial or residential areas, places with high traffic, barriers and elevators, large office buildings, government and financial institutions, airports, railway stations, hotels, universities, industrial zones and sites with special purpose.
Control of working hours* - Reports for time worked, delays, absence, overtime, holidays and more. Reports can be individual or summarized performance calculated by hours, minutes, rates and more. Export data in various formats (txt, xls, etc.).
Management of prepaid and postpaid cards* based on time or based on number of visits (Entries) - allows charging by contactless cards. Charging of prepaid tickets - after the paid subscription period is over the rights of the card (user) are automatically revoked. Suitable for basic hotel systems, charging and control of parking lots and garages, gyms, SPA centres etc.
Area management* - visitor counting overall or in certain areas
Visitor management* - easy issuing and controlling of temporary rights for certain areas of the site.The visitor receives a contactless card (pass) on the reception or the parking lot. suitable for commercial buildings, offices, large office buildings, government and financial institutions
Print management and badges* - In House and visitor badges
Management of remote sites* - Remote control and monitoring of multiple service facilities located at a distance from one another. Head offices of banks and branches, industrial facilities and shops, hotels, highschool campus buildings etc.
Intuitive management of different users with different rights* - easy definition of access groups with different rights for different areas
* available in conjunction with the software package Andromeda Pro
| User capacity | 8100 or 16 400 |
| Transaction capacity | 4100 or 8200 |
| Input ports | 8 Isolation inputs, 1 analog input (0-10V) |
| Outputs ports | 5 Relay outputs (125V/3A); 2 O.C. outputs (30V/0.5A); Output Siren with special function (detect line status of siren) |
| Communication | LAN, RS 232 C, RS 485 |
| Voltage | 230V AC |
| Current (mA) | 300 |
| LED indicator | Yes |
| Beeper | Yes |
| Operating temperature | -10°C-+50°C |
| Operating humidity(RH) | 10 % - 90 %RH (non condensing) |
| Dimension (mm) | 158*91*46 |
| Warranty (Years) | 2 |
| Software | Free, Paid |
