ICON 120 Access Control Panel

Name: ICON 120 Access Control Panel
Brand: Polimex
SKU: 102491389

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Bulgaria

Brand Name:

Polimex

Model Number:

iCON120

Polimex Holding Ltd

Payment & Shipping

Payment Methods:

Port of Shipment:

Sofia

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Bulgaria

Brand Name Polimex

Model Number iCON120

Specifications

Intelligent Single or Double Door Access Controller Panel;
Dynamic Control of Memory up to 8000 Users / up to 4 000 Events

Intelligent Single or Double Door Access Controller Panel;

Dynamic Control of Memory up to 4 000 Users / up to 8 000 Event Buffers ;
Independent 3 Inputs and 2 Relay Outputs;
Standalone / Network Communication via RS-232, RS485 (Max.253ch) ;
Operation mode: PIN Only, RFID Card Only; PIN or RFID Card; RFID Card+PW; RFID Card +PIN
2 Reader Ports;
Anti-Passback Function;
Duress Mode Function;
Power supply 220VAC;
Monitoring and management;
Communication Status via LED Indicator ;
Remain ID & Event Data and Setting Value in case of Electric Outage ;
Modification: iCON120LT

User capacity	8000
Transaction capacity	4000
Input ports	3ea (2xExit Button, Emergency, Battery)
Outputs ports	2ea (2 Relay outputs-3A/48VDC, 2 x Wiegand 26 bit )
Communication	RS 232 C, RS 485, Wiegand 26 bit-input
Voltage	220 VAC; Optional: 14 AC/DC
Current (mA)	250
LED indicator	Yes
Beeper	No
Operating temperature	-25°C-+75°C
Operating humidity(RH)	0% - 90% (non-condensing)
Dimension (mm)	1059058
Certification	CE, RoHS
Warranty (Years)	2
Software	Free, Paid
Downloads	No
