12ton Hydraulic Single Drum Vibratory Road Roller

FOB Price

Negotiable / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New		Type	Single Drum Roller
Brand Name	XCMG		Model Number	XS122

12ton Hydraulic Single Drum Vibratory Road Roller

Main Features

1.Smooth tire, hydraulic single drive, articulated steering;

2.Continously Variable Transmission;

3.Oil-cut brake, safe and reliable;

4.Streamline outlook, circular windshield glass cabin;

5.Travel motor adopts SAUER brand piston motor;

6.Large capacity water tank, drum with sprinkler and scraper device;

7.Removal padfoot is optional.

Type	Unit	Specifications
Operating weight	kg	12000
Weight on front drum	kg	6700
Static linear load	N/cm	308
Speed range	km/h	0~10.4
Theoretical gradeability	%	45
Min. external turning radius	mm	6800
Steering angle	°	±30
Oscillating angle	°	±10
Vibration frequency(L/H)	Hz	30/35
Nominal amplitude(H/L)	mm	1.80/0.9
Excitation force(H/L)	kN	290/180
Drum diameter	mm	1523
Drum width	mm	2130
Engine model		Cummins 4B3.9
Type		Water cooled, turbo-charged,air-air intercooling
Rated power @2200r/min	kW	93
