Main Features
01Hydraulic double wheels drive,hydraulic front drum vibration and steering ,with reliable performance and optimum function ratio；
02LTC203P hydraulic front and rear wheels drive ,hydraulic front drum vibratory；
03Both front and rear wheels have scraping and water spray unit,advanced sprinkler pump system can achieve intermittent ,greatly expanded mechanical proper working condition；
04Adopt ZN390B diesel engine,Energy conservation and environmental ,very convenient for use and maintenance；
05Compact integral structure,small volume ,capable of used for compaction on narrow site ,with small investment ,quick return of good economic；
06LTC203P rear wheel adopts combination of four slick tires,and has double function,of wheel roller and tire roller,which can effectively improve the rolling quality of asphalt pavement ,and improve the climbing ability；
07LTC203P walking more stable ,damping effect；
08LTC203P High-end seats,has greatly enhanced operator comfort ,reduce fatigue.
MODEL |
LTC203P |
LTC204P |
LTC203 |
|
Operating mass |
kg |
3000 |
4000 |
3400 |
Static linear load |
N/cm |
120/103 |
150/150 |
130/130 |
Vibration frequency |
mm |
0.5 |
0.5 |
0.5/0.5 |
Centrifugal force |
KN |
30 |
40 |
2*30 |
Vibration frequency |
Hz |
50 |
60 |
50 |
Travel speed |
Km/h |
0-12 |
0-12 |
0-12 |
Grade ability |
% |
32 |
40 |
30 |
Steering angle |
。 |
+26 |
+26 |
+26 |
Overall dimension |
mm |
2760*1400*2580 |
2850x1520x2700 |
2760*1400*2520 |
Drum diameter |
mm |
700 |
900 |
700 |
Drum width |
mm |
1250 |
1400 |
1250 |
Quantity of rear tire |
Pic |
4 |
4 |
/ |
Specification of rear tire |
7.50-15 |
10.5/80-6 |
/ |
|
Thickness of steel wheel |
mm |
12 |
12 |
12 |
Turning Radius |
mm |
2800 |
3000 |
2800 |
Water Tank Volume |
L |
200 |
240 |
200 |
Diesel power/model |
23kw/ZN390Q |
36kw/ZN490B |
23kw/ZN390Q |
