Help Center100HP Mini Motor Grader for Sale
Related Products
Specifications
1.2012 XCMG new Motor Grader2.China or Original Cummins engine, 100HP
3.Meritor axle
4.Hangzhou or ZF transmission
HP100 GR100 Motor Grader for sale
Motor Grader GR100
main parameters
Basic specification | |
Engine model |
4BT3.9 |
Rated power/speed |
75/2400kw/rpm |
Dimension(LxWxH) |
6880×2375×3150mm |
Operating weight(Standard) |
7000kg |
Performance specification | |
Travelling speed ,forward |
5,10,20,39km/h |
Travelling speed ,reverse |
8,25km/h |
Tractive force(f=0.75) |
41.6KN |
Max. gradeability |
20% |
Tire inflation pressure |
350KPa |
Working hydraulic pressure |
16MPa |
Transmission pressure |
1.3~1.8MPa |
Operating specification | |
Max. steering angle of front wheels |
±50° |
Max. lean angle of front wheels |
17° |
Max. oscillation angle of front axle |
±15° |
Max. oscillation angle of balance box |
|
Frame articulation angle |
±27° |
Min. turning radius using articulation |
5.9m |
Biade | |
Maximum lift above ground |
300mm |
Maximum depth of cutting |
350mm |
Maximum blade position angle |
45° |
Blade cutting angle |
28°—70° |
Circle reversing rotation |
120° |
Moldboard width X height |
3048×500mm |
Other models:
Large ranges of machinery( abundant pre-sale service):
We look forward to cooperate with you:
- Contact us:
- Web:
- Name: Kevin Powter
- Tel: 86-13805322962
- Skype: zag481718
- Email: sales#
