Specifications
1.2012 XCMG new Motor Grader2.China or Original Cummins engine, 200HP
3.Meritor axle
4.Hangzhou or ZF transmission
200HP GR200 Motor Grader for sale
Motor Grader GR200
Main Parameters
Basic specification | |
Engine model | D6114 ZG14B |
Rated power/speed | 147kW/2200rpm |
Dimension(LxWxH) | 8932×2625×3470mm |
Operating weight(Standard) | 16000kg |
Performance specification | |
Travelling speed ,forward | 5,8,11,19,23,38 km/h |
Travelling speed ,reverse | 5,11,23 km/h |
Tractive force(f=0.75) | 82KN |
Max. gradeability | 20% |
Tire inflation pressure | 260 kPa |
Working hydraulic pressure | 16 MPa |
Transmission pressure | 1.3~1.8MPa |
Operating specification | |
Max. steering angle of front wheels | ±50° |
Max. lean angle of front wheels | ±17° |
Max. oscillation angle of front axle | ±15° |
Max. oscillation angle of balance box | 15 |
Frame articulation angle | ±27° |
Min. turning radius using articulation | 7.3m |
Biade | |
Maximum lift above ground | 450mm |
Maximum depth of cutting | 500mm |
Maximum blade position angle | 90° |
Blade cutting angle | 28°—70° |
Circle reversing rotation | 360° |
Moldboard width X height | 4270×610mm |
Other models:
