Briquetting Peat Machine
Features of the briquetting peat machine
1. Mature technology design ; durable quality ;
2. Simple structure but excellent making effect ;
3. Easy to operate, small in size, power saving ;
4. Can adapt continuous produce with large capacity / output .
Our briquetting peat machine helps in develop high quality Briquettes and waste material recycling. As a manufacturer, exporter, and supplier, we have the expertise to design and develop premium grade briquette machine to assure smooth production of briquettes in varied sizes. Binder and adhesive material used should be of high quality that makes the process easier and qualitative.
Briquetting peat machine also be knew as powder material ball press machine and charcoal
powder briquette machine .
Suitable material for the briquetting peat machine
Charcoal powder, coal , coal powder, charcoal pulver ,carbon powder,
bamboo carbon powder, coke powder, shisha
powder, graphite powder, coconut powder,
ZaoMu Carbon, LAN carbon powder, active carbon ,etc .
With the briquetting peat machine, can get 30-60mm diameter oval, pillow, square, and other shape briquettes product, the size and shape can be customized .
pl note : Also, the waste material from the wood , or straw, crop straw, biomass material is available as well, but we should use carbonization first to char the biomass raw material, then, put into thebriquetting machine to be shaped .
The working principle of the briquetting peat machine
Briquette Machine motor will pass the power on to the two pressure roller through the reducer. The two sides and roller rotation, in both the rotating direction, material fulfill the space between two rollers, with the roller rotation, pressure on material will be bigger and bigger. When the material reach the two rollers rotating line contact point, the pressure reach the peak. After press, the briquette will drop by gravity.
Application area of the briquetting peat machine
Refractory industry, power plant, metallurgy industry, chemical, energy, transportation, heating,
animal husbandry, industry, agriculture, barbecue, and other fields.
Working types of the briquetting peat machine
The machine is suitable for a single job and largescale assembly production line , also can adapt to the liquidity operations.
Packing of the briquetting peat machine
1. with wooden case for single machine, small size machine
2. with container for big size machine, large quantity machine, or complete production line
Main technology parameter for the briquetting peat machine
Model |
WLXM-360 |
WLXM-400 |
WLXM-500 |
WLXM-650 |
WLXM-750 |
WLXM-850 |
WLXM-1250 |
Capacity |
2~4 t/h |
6~8t/h |
8~11t/h |
13~18 t/h |
18~25t/h |
25~35 t/h |
40~70 t/h |
Annually capacity |
10,000 t/h |
20,000 t/h |
30,0t00 t/h |
50,000 t/h |
70,000 t/h |
100,000 t/h |
200,000 t/h |
Dia. Of rollers |
360mm |
400mm |
500 |
650mm |
750 |
850mm |
1250mm |
Width of rollers |
250 |
280 |
300 |
336 |
400 |
500 |
650 |
Motor power |
7.5 kw |
11~15kw |
18.5~22kw |
20~30 kw |
45kw |
75 kw |
130 kw |
Rotation speed |
18 r/min. |
15r/min. |
13r/min |
13 r/min. |
13r/min |
10 r/min. |
10 r/min. |
Shapes of briquettes |
Oval or pillow or square or customized |
||||||
Sizes of briquettes |
As your specific requirement ( usually 20~80mm ) |
||||||
Available shapes of the briquetting peat machine
Square, oval, pillow, ball type, or customized .
Moisture demands of the coal briquetting machine : usually 8%-12% .
Sizes demands of the coal briquetting machine : less than 5mm in general .
With binder or not ?
With this type coal briquetting machine ,it’s up to you, with binder can enhance the cold
strength and thermal intensity , if you do not need, just neglect the binder .
With dryer or not ?
First, if the raw material is too wet (raw moisture more than 45%), then should dry the wet
material before to be formed ; second, the final briquettes to be dry or not, it’s up to you as well.
If the working place has not much strict requirements to the briquette’s moisture, or the device
can handle the briquette directly, then there can without briquettes mesh belt dryer .
Our Services of the briquetting peat machine
Our service of the briquette machine
1. If any interest on our briquette machine, please feel free to contact me and let me know your requirement on capacity and material size.
2. We are professional machine manufacturer, we will help to choose the most suitable machine for you.
3. Whole plant design and drawings are free after set order.
4. Quality Commitment: Quality Warranty, Grantee Period: 1 year. Supply wearing parts with favorable price and long term after-sales service.
5. If you need, we will dispatch professional engineer for installation, trail and worker training.
Company brief introduction of the briquetting peat machine
Henan province zhengzhou city weilite machinery plant is the professional manufacture for making different kinds new type briquette/briquetting peat machine, importing international advanced technical, use and improve the newest design conceptof different machines to make more high efficiency, power saving and durable shape briquetting machine .
If any interest to our briquetting iron ore powder machine / mineral powder briquetting machine, please contact me for more details.
Tel:+86 (0)371 86687769
Cell Phone/what's app:+86 18237163670
Contact person: Ashley Gao(Sales Manager)
Skype: ashley weilite or email me .
