Specifications
micro powder pulverizing machine1.Feeding: 28mm
2.Discharging:30-400mesh
3.Power:7.5-75kw
4.Fine Discharging Size
- This micro powder pulverizing machine is mainly used to make the ore into powder,such as metallurgy,building materials,chemical and mining.
- Micro powder pulverizing machine can product powder form various non-flammable and non-explosive mineral materials whose mohs hardness is below 9.3 and humidity below 6%,etc.
Micro Powder Pulverizing Machine Mainly Parts
Micro Powder Pulverizing Machine Working Theory
Firstly, gold ore will be crushed by jaw crusher to reduce size below 10-25mm, and then the crushed materials are elevated into a hopper from which the material is transported through the electro-magnetic vibrating feeder evenly and continuously into the grinding chamber for powder-processing. The rollers of raymond pulverizer oscillate outward to press the ring because of the centrifugal force and the shovel scoops up the materials, send to the middle between ring and roller to accomplish the grind.
Micro Powder Pulverizing Machine Technical Datas
Model |
3R1410 |
3R1815 |
3R2115 |
3R2615 |
3R2715 |
3R3016 |
4R2715 |
4R3016 |
4R3216 |
5R4119 |
|
Max feeding size (mm) |
10-15 |
10-15 |
10-15 |
15-20 |
15-20 |
20-25 |
15-20 |
20-25 |
20-25 |
20-30 |
|
Output size (mesh) |
60-325 |
|||||||||
|
Shift output (t/8h) |
1-10 |
1.3-14 |
1.5-16 |
2-24 |
2-29 |
3-34 |
2-31 |
3-35 |
3-39 |
5-66 |
|
Roller diameter (mm) |
140 |
180 |
210 |
260 |
270 |
300 |
270 |
300 |
320 |
410 |
|
Main power (kw) |
7.5 |
11 |
15 |
18.5 |
22 |
30 |
22 |
30 |
37 |
75 |
|
Blower power (kw) |
5.5 |
7.5 |
11 |
18.5 |
18.5 |
22 |
18.5 |
22 |
30 |
75 |
|
Analyzer power (kw) |
1.1 |
1.5 |
2.2 |
2.2 |
2.2 |
2.2 |
2.2 |
2.2 |
5.5 |
7.5 |
a). If any interest in our micro powder pulverizing machine, please feel free to contact me and let me know your requirement on capacity,feeding material size and discharging material size.
b). We are professional machine manufacturer, we will help to choose the most suitable machine for you.
c). Quality Commitment: Quality Warranty, Grantee Period: 1 year. Supply wearing parts with favorable price and long term after-sales service.
d). If you need, we will dispatch professional engineer for installation, trail and worker training.
Zhengzhou Weilite Machinery Equipment Co., Ltd is a manufacturer and exporter of mining machine in China. Our main products are crusher, grinding mill, dryer, briquette machine and so on. They are excellent quality and enjoy good reputation both in China and overseas. Welcome to visit and purchase from us!
1).What's the max. feeding material size for the micro powder pulverizing machine?
- Answer:25mm.
2).What's the discharging material size for the micro powder pulverizing machine?
- Answer:Discharging material size varies from 125mesh to 1250mesh.
3).What kind of material can be grinded by your micro powder pulverizing machine?
- Answer:Gold, Calcite, Bentonite, Clay, Cement Clinker, Coal,Gypsum,Steel Slag,Iron Ore,Chrome Ore,etc.
4).Do you provide production line design service for the micro powder pulverizing machine?
- Answer:Yes, we are professional machine manufacturer. So we can provide production line design service.
If any interest in our micro powder pulverizing machine, please contact me for details.
Tel:+86 (0)371 86687769
Cell Phone:+86 15639260527
Contact Name:Ms. Sandy Shi
