micro pulverizer for grinding sand
1.Brief Introduction Of Micro PulverizerFor Grinding Sand
- Micro pulverizer for grinding sand is suitable for grinding the sand,barite, limestone, kainite, Ceram and slag, etc. which below scale 9.3 of Moth and below 6% shadiness and 280-odd sorts of non-inflammable and non-explosive stuff in the trades of mining, metallurgy, chemical engineering and building material for high fine powder generating and processing.
- The Product size is adjustable in the range of 80-425 mesh. The limestone grinder is possible to produce 30-80 mesh coarse powder through special device in the machine.
2. Micro Pulverizer For Grinding Sand Advantages
1.Three-dimensional structure
2.The screen-passing rate can reach 99%
3.Lower oil and power consumption
4. Unique design more effective than traditional machines
5.The transmission device of mainframe adopts airtight gear case and zonal wheel
6. Centralized control for the electric system, convenient to operate
7. Higher productivity and capacity utilization
8. Meet the latest environmental standard
3. Micro Pulverizer For Grinding Sand Working Principle
Raw material which has been crushed to the size specified is elevated into a hopper from which the stuff is loaded. And then through the vibrating feeder ,the materials will transferred evenly and continuously into the raymond mill grinding chamber for powder-processing. After this,the ground stuff is carried by the air from the blower into the classifer for regrinding.The set's airflow system is closely sealed up and circulated under the condition of negative and positive pressure. The raymond mill is driven by rotation of the central axle through decelerator ,with the up end of the axle connecting to a quincunx-rack upon which the grinding equipment is fixed. The whole set equipment turns together with the axle along the grinding ring while the rollers rotate driven by the fractional force .A set of shovel are installed at the lower end of the quincunx-rack.While turning together with the rollers ,the shovels shed the stuff onto the gap between the rollers and the ring ,and that's where the stuff layer forms .The rotating rollers ,while turning together with the ring ,grind the stuff layer into powder. The turning speed of the impeller can be adjusted to the requirement of the fineness of powder products .Raymond mill plays an important role in ensuring the function of the grinder . As the high-speed revolving air current mixed with ground stuff is flown into the cyclone-collector ,the ground stuff is separated from the air-current.
4. Micro Pulverizer For Grinding Sand Main Technical Parameter
Model |
3R1410 |
3R1815 |
3R2115 |
3R2615 |
3R2715 |
3R3016 |
4R2715 |
4R3016 |
4R3216 |
5R4119 |
|
Max feeding size (mm) |
10-15 |
10-15 |
10-15 |
15-20 |
15-20 |
20-25 |
15-20 |
20-25 |
20-25 |
20-30 |
|
Output size (mesh) |
60-325 |
|||||||||
|
Shift output (t/8h) |
1-10 |
1.3-14 |
1.5-16 |
2-24 |
2-29 |
3-34 |
2-31 |
3-35 |
3-39 |
5-66 |
|
Roller diameter (mm) |
140 |
180 |
210 |
260 |
270 |
300 |
270 |
300 |
320 |
410 |
|
Main power (kw) |
7.5 |
11 |
15 |
18.5 |
22 |
30 |
22 |
30 |
37 |
75 |
|
Blower power (kw) |
5.5 |
7.5 |
11 |
18.5 |
18.5 |
22 |
18.5 |
22 |
30 |
75 |
|
Analyzer power (kw) |
1.1 |
1.5 |
2.2 |
2.2 |
2.2 |
2.2 |
2.2 |
2.2 |
5.5 |
7.5 |
5.More Pictures About Micro Pulverizer For Grinding Sand
6.Micro Pulverizer For Grinding Sand Packaging And Shipping
7.Our Services About Micro Pulverizer For Grinding Sand
1)Pre-sale services: Enthusiasm
- We provide you with the prophase plan, process flow design and manufacturer equipment according to your special demand.
2)Sale services: Servant
- Send technicians to the jobsite for guiding the installation and adjustment, training operators and finishing the check and accept together with you.
3)After-sale services: Faithfulness
- To establish long term friendship, we will regularly pay return visit to customers. Supplying technique, building design, instruction, installation and debugging for free.
4)We provide one-year warranty to make sure your machine runs consistently.
- We always offering lifelong services and provide spare parts for a long term,and repair main parts under right using for free in one years.
8.About Us
Zhengzhou Weilite Machinery Equipment Co.,Ltd. is a professional mining machine manufacturer, our main machines are crusher, mixer, briquette machine,conveyor belts, etc. Website: /. All of them are high quality and warmly welcome by our customers.
9. FAQ About Micro Pulverizer For Grinding Sand
1.What's the range of application of the micro pulverizer for grinding sand?
- Answer: It applies in all kinds of mineral powder preparation and coal powder preparation.
2.What's the scale of the hardness of the micro pulverizer for grinding sand?
- Answer: There are two kinds, one is the absolute hardness and another is relative one.
3.What's the operation sequence about the micro pulverizer for grinding sand?
- Answer: Hoist --crusher → Analyzer → fan → Host → machine feeder.
