Specifications
Material :Stainess steel3045 Stage water purification
Uf membrance:famous brand
Output water capacity:3000L/H
Control valve
Mineral water plant
Features:
1. Automatic backwash and manual backwash.
2. Automatic switch on when low water level, and switch off when high water level.
3. Water shortage protection for multi-stage pump
4. Protection when no voltage, under-voltage, over-current, short circuit and creepage.
5. Full stainless steel structure, durable and easy to clean.
6. Integrating water flow indicator, TDS indicator, pressure indicator, control panel
7. China Top Brand or world famous brand electrical, switch and valve systems
8. Built-in soft-start system to avoid damage to the expensive membrane when starting.
Specification:
Product |
Automatic 3000L/H Ultrafiltration Water Treatment Equipment / Water Treatment Machine / Water Treatment System |
Model |
UF-3000L |
Purified Water Production Capacity |
3,000 litres per hour (temperature=25oC) |
Input Power |
AC380V/50Hz/1.03KW |
Quartz Sand Filter |
SUS304 tank Φ500×1200×t1.5mm×1PC (including 250KG quartz sand) |
Active Carbon Filter |
SUS304 tank Φ500×1200×t1.5mm×1PC (including 125KG active carbon) |
PP Sediment Filter |
SUS304 tank Φ330×500×t1.5×1PC (including PP filter ×3PCS) |
Booster Pump |
Denmark GRUNDFOS CH8-30 pump×1PC / 1.03KW |
Ultrafiltration System |
Hollow-fiber Filter×6PCS |
Dimension |
Main machine: 2100×660×1600mm |
Besides water treatment system, we also offer UV Sterilizer, Ozone Sterilizing System, full set 0.3~2.0L/4~6L/3~6gallon mineral water / pure water filling / bottling line equipments, factory design, and installation service.
Pls also kindly undertand that every water treatment equipment, no matter ultrafiltration or reverse osmosis, is a ODM project as different water is of different quality. Therefore, we would require for a raw water analysis / test report for inquiries of water treatment system for any inquiry.
Hurry and contact our sales engineer today for your own water treatment solution!
1.which kind of raw water can be purified by this machine ?
Answer: City water standare or clean underground water /rever water .(it is better for you send us the raw water test report)
2.what is the time to update each filters ?
Answer: This is up to your raw water quality ,normally , sand&active carbon filter 1-2 year update , and PP filter each 3-4 month
UF membrance 1 year need update .
3.can the mineral water produced drinkable ?
Answer:Sure , water after UF membrance is called mineral water ,which is drinkable .
4.can this machine include UV lamp and ozone device ?
Answer: no ,this is a 4 stage watrer purifier machin not include UV and ozone device ,for most of drinking water factory ,you may need pay extra money to purchase from us ,we will give you reasonable price and intallation them on the main machine .
5.how many pump is include in this system ?
Answer: 1 pump only , this is UF system ,just need a boost pump .
6.can this mineral water mixed to make juice water and carboned drinking water ?
Answer: Yes , mineral water system did maintain water nutrient ,it is better to do juice/carboned water ,
2012 Export to Bangladesh mineral water 1000L/H machine
2014 Export to Ghana 3000L/H machine
2013 Export to Jordan 5000L/H machine
2014 Export to Kingdom of Saudi Arabic 8000L/H machine
2013 Export To Haiti 15,000L/H machine
This machine will be packed is export wooden case , for the shippment and freight confirmation , please notice us your nearest port ,we will reply you the best freight and date of arrive .
Developing from our honorable controled company of Shenzhen Angel Drinking Water Equipment Co., Ltd., Shenzhen Kinglife Environmental Technology Co., Ltd. is engaged in the R&D, manufacture and marketing of ultra-filtration (UF) / reverse osmosis (RO) water filters and water purifiers.
Corporate History & Honors:
2001 - Shenzhen Kinglife Environmental Technology Co., Ltd. was founded.
2002 - Our ultrafiltration water filters were launched into the market.
2003 - Our reverse osmosis water purifiers were launched into the market.
2004 - We were invited to join Water Quality Association.
2004 - Our ultrafiltration water filters were awarded "Top Ten Brand in China" and "Environmental Protection Products".
2005 - Our filter products were notarized and awarded "Top Ten Quality Brands of Filter Products in China".
2005 - Our KDF filters were successfully patented and later were awarded "National Technology Invention Award" and "National Science and Technology Progress Award".
2005 - We were awarded "Asia Pacific (International) Environmental Protection Scientific and Technological Innovation Award" and became an honorable member of Asia Pacific Environmental Protection Association.
2008 - Our products were awarded "China Well-Known Brand".
With the support of our parent company, we also provide the following products and services:
1. Design, installation and training of reverse osmosis / ultrafiltration water treatment equipment with production capacity ranging from 300L/H to 100,000L/H
2. Design, installation and training of full sets of 0.25L to 6L small bottle mineral / pure water bottling lines
3. Design, installation and training of full sets of linear / monoblock type semi-automatic and fully automatic equipment with production capacity up to 34,000BPH (bottle per hour)
4. Design, installation and training of full sets of 3/5/6 gallon semi-automatic and fully automatic water filling & packaging production lines with production capacity from 30BPH to 1,200BPH
5. Design, installation and training of full sets of juice / carbonated drink filling & packaging production lines
6. Design, installation and training of 0.05 cubic meters/hour to 20 cubic meters/hour sea water desalination equipment for villas, boats and small islands.
7. Automatic water vending machines for dormitories, schools and living area
8. Water dispensers / coolers for families or offices
We are honored to announce the following customer list:
1. Walmart China - constant pressure pure water supply
2. Carrefour China - pure drinking water supply
3. BYD - pure water bottling plant supply
4. TCL - pure drinking water supply
5. Culligan Haiti - sachet pure water filling plant, 0.5~1.5L pure water bottling plant, 5gallon pure water bottling plant
6. M2O Sudan - 600ml and 1500ml mineral water bottling plant
7. AQUAPLUS Montenegro - 0.5~1.5L and 5gallon pure water filling plant
