Specifications
1.High throughput, low roll speed2.Primary/secondary/tertiary crushing
3.Reliable performance
Brief introduction of mining stone classification crusher
Raw coal crusher adopts shearing-crushing technology, basically eliminating over crushing phenomenon.
Suitable for the primary, secondary and tertiary crushing stage in borehole operation, opencast mine,plant crushing system.
Feeding raw material of mining stone classification crusher
Soft to medium, hard materials such as coal, coke, limestone, lignite, slag and similar raw materials.
Applicable Industry of mining stone classification crusher
Cement, chemical, power station, metallurgy, building material, refractory material industries, etc.
Operation mode of tooth roll mining stone classification crusher
1.In the primary stage, the feed material undergoes a size reduction between the counter-rotating rolls running inwards inside the center crusher.
2. In the secondary and tertiary crushing stage, the material is crushed between rolls rotating outwards and the crushing comb. In both cases, size reduction is effected by shear and tensile forces, generated by high roll torques at low circumferential speeds.
Characteristics of mining stone classification crusher
1. Simple, compact, sturdy and reliable design;
2. High throughput capacities;
3. Wear-resistant steel crushing tooth configuration with long service life;
4. Fast and easy replacement of components and wear parts;
5. ISO9001:2008 certification.
Technical parameter
Model |
Feed grain (mm) |
Material-out size (mm) |
Capacity (t/h) |
Motor power (kW) |
Weight (t) |
5050 |
200 |
35-50 |
30-70 |
2×11 |
4 |
50100 |
200 |
35-50 |
60-80 |
2×15 |
5 |
50150 |
200 |
35-50 |
80-120 |
2×18.5 |
7 |
6550 |
300 |
50-80 |
80-100 |
2×15 |
6 |
65100 |
80 |
13 |
30-50 |
2×18.5 |
7 |
65150 |
80 |
13 |
50-80 |
2×22 |
7.5 |
75100 |
80 |
13 |
80-120 |
2×22 |
8 |
75150 |
350 |
50-150 |
150-420 |
2×30 |
10 |
75200 |
350 |
50-150 |
200-560 |
2×45 |
15 |
100100 |
600 |
50-150 |
240-700 |
2×37 |
12 |
100150 |
600 |
50-150 |
350-900 |
2×45 |
15 |
100200 |
600 |
50-150 |
450-1200 |
2×55 |
18 |
