Specifications
spiral chute separator machine:1.Non-power
2.Easy operation&low maintainence
3.High recovery,low price
4.CE&SGS&ISO
sand separator machine china distributor
Descriptions of sand separator machine china distributor:
Gravity mining machine spiral chute separator is our company’s concentrating experienced scientific product, which is the best concentrating equipment, especially for concentrating sand ore in beach, riverside, seashore and stream. The product is made of the fiberglass lined with wear-resistant resin and emery. It is the domestic advanced level, the new highly effective equipment, it has been widely used in to enrichment the particle size 0.3-0.02 millimeters fine grain like iron, tin, chromite, ilmenite, tungsten, zinc, tantalum-niobium, gold, coal, monazite, rutile, zircon , other low-grade ores or non-metallic minerals which have a enough specific gravity difference.
We make the serialized with a special kind of grooved Gravity mining machine spiral chute separator to be selected by colored, ferrous metal mine, coal chemical industry, coal dressing, sulfur factory as well as the scientific research, the design department, the colleges and universities test chamber.
Advantages and Characteristics of sand separator machine china distributor:
High recovery, high efficiency, and precise separation
Non-required power
Light in weight, anti corrosion, rust and wear resistant
Low operating cost and long working life
Strong adaptability to fluctuation of feeding amount, density, size and grade
The surface of emery forms strong friction the concentration effect surpass plastic surface
Technical Specification of sand separator machine china distributor:
5LL-2000 |
5LL-1500 |
5LL-1200 |
5LL-900 |
5LL-600 |
5LL-400 |
||
Spiral Diameter(mm) |
2000 |
1500 |
1200 |
900 |
600 |
400 |
|
Spiral Pitch(mm) |
1200 |
720/540 |
900/720 /540 |
675/540 /405 |
450/360 /270 |
240/180 |
|
Starts |
3 |
4 |
4 |
4 |
2 |
2 |
|
Feeding Sizes (mm) |
4-0.04 |
0.8-0.037 |
0.3-0.03 |
0.3-0.03 |
0.2-0.02 |
0.2-0.02 |
|
Feeding Density (%) |
20-45 |
30-60 |
25-35 |
25-55 |
25-55 |
25-55 |
|
Capacity (t/h) |
15-40 |
6-8 |
4-6 |
2-3 |
0.4-0.8 |
0.15-0.2 |
|
Dimension (mm) |
Length |
2300 |
1560 |
1360 |
1060 |
700 |
460 |
Width |
2300 |
1560 |
1360 |
1060 |
700 |
460 |
|
Height |
6500 |
5230 |
5230 |
4000 |
2600 |
1500 |
|
Weight(Kg) |
1100 |
800 |
600 |
400 |
150 |
50 |
|
Note: This specification is just reference, any changes are subject to the products.We can produce equipment as your special requirement, Welcome to customization!
Pictures of sand separator machine china distributor:
Mining machines design and manufacture.
Technical engineer is available to the construction site for installation instruction and trial operation.
Customization is available.
Why Choose Us?
We are the manufactory, we can provide you ex-factory price;
Strictly quality control system;
Professional technical online service;
Any mail or message will be replied within 8 hours;
Completive manufactory price;
We have many large ore dressing line;
We will provide equipment operation training for our client;
We have a professional after-sale service team to promptly solve your problems.
If you want to get more information,please provide the following information:
1. Type of rock (granite, basalt, limestone, etc.)?
2. What is the maximum size of your stone?
3. What size ranges of final product do you want to make?
4. How many tons per hour do you want to be able to process?
