High Qulity European Standard Circular Vibrating Screen

High Qulity European Standard Circular Vibrating Screen thumbnail-1
High Qulity European Standard Circular Vibrating Screen photo-1
US$ 1,000 - 700,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Mining,Building,Smelting,chemical industry,mineral feeder.
Power Type:
Electric
Contact Supplier Request Quote Chat Now
Zhengzhou Huahong Machinery Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China main ports
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Mining,Building,Smelting,chemical industry,mineral feeder.
Power Type Electric
Capacity(t/h) 30-100t/h
Place of Origin Henan, China
Brand Name Huahong
Model Number 3YK1235
Power(W) 7.5 kw
Dimension(L*W*H) 4400*1900*1200
Weight As per different model
Certification ISO,CE
Warranty one year
After-sales Service Provided Engineers available to service machinery overseas

Specifications

circular Vibrating screen :
1.Evenly feeding
2.Long sevice life
3.Low power consumption

  High Qulity European Standard circular Vibrating screen

1) Introduction of  circular vibrating screen machine

 Vibrating Screen are used to separate materials into various sizes for further processing, or for end use. Depend on our need. The material is separated by passing it through a vibrating “screen box” which has a number of different sized screens, or meshes, which the material falls through like a sieve, the material falls onto attached conveyors which stock pile the end products. The end products can then be used in the building and construction industries.



2) Features of circular vibrating screen machine

1.Simple and reasonable structure

2.Good continuity, adjustable exciting force.

3.Easy operations and maintenance.
4.Good regulating performance, no material clashing.
5.Stable vibration, reliable work.

6.Low noise, less power consumption.

7.Reliable work, long life.







3)Main parameters



Model Spec. Layers Screen area Sieve pore size Max feed size Capacity Weight Power Overall dimension
(mm) (m2) (mm) (mm) (t/h) (t) (kw) (L×W×H) (mm)
2YK1235  1200×3500  2  4.2 5-50  400  15-100  3.2  5.5  4090×1900×800
3YK1235  1200×3500  3  4.2  5-50                                 400  30-100 4.4  7.5  4400×1900×1200
2YK1545  1500×4500  2  6.75 5-50  400  50-180  5.3  15  5400×2250×1600
3YK1545  1500×4500  3  6.75 5-50  400  50-210  6.1  15  5400×2250×1700
4YK1545  1500×4500  4 6.75 5-50  400  50-240  6.9  18.5  5400×2250×1700
2YK1860  1800×6000  2  10.8 5-80  400  50-330    8 22  6960×2600×1630
3YK1860  1800×6000  3  10.8 5-80  400  50-360  8.6  22  7100×2680×1710
4YK1860  1800×6000  4 10.8  5-80  400  50-390  9.2  30  7242×2680×2046
2YK2160  2100×6000  2 12.6  5-100  400  100-400  8.8  30  7054×2990×1495
3YK2160  2100×6000  3 12.6  5-100  400  100-430   9.45  30  7220×2990×1952
4YK2160  2100×6000  4 12.6 5-100  400  120-460  10.9  45 7390×2990×2412
2YK2460  2400×6000  2 14.4  5-100  400  150-500 9.63  37 7054×3280×1495
3YK2460  2400×6000  3  14.4  5-100  400  150-550 11.5 45  7220×3280×1952
4YK2460  2400×6000  4 14.4  5-100  400  180-600  12.78 55 7390×3280×2412



Note: If the type is not what you need, please contact us and more other types are available.

Also, we are pleasure to special design  for you according to your needs.



High Qulity European Standard circular Vibrating screenHigh Qulity European Standard circular Vibrating screenHigh Qulity European Standard circular Vibrating screenHigh Qulity European Standard circular Vibrating screenHigh Qulity European Standard circular Vibrating screenHigh Qulity European Standard circular Vibrating screenHigh Qulity European Standard circular Vibrating screen



4)Stone-Making Production LineHigh Qulity European Standard circular Vibrating screen

Stone production line:

Including:

Jaw crusher

Impact crusher

Cone crusher

Hammer crusher

Vibrating screen etc

*In order to find the suitable models and design the best stone crusher plant or sand making line for you, please kindly inform us the following information:

1.Material Property

2.Capacity

3.Output Size

4.Types of Output

5.Site Conditions and Purpose.

Thank you for your cooperation!

If  you have any other questions, please feel free to contact us!
