Help CenterTY-550S Vertical Injection Molding Machine
Related Products
-
TY-200DS Vertical Plastic Injection MachineNegotiableMOQ: 1 Set -
TY-550.2R Vertical Injection Molding MachineNegotiableMOQ: 1 Set
-
Vertical Plastic Injection Molding Machine 40tonNegotiableMOQ: 1 Set
-
TY-200 Vertical Plastic Injection Molding MachineNegotiableMOQ: 1 Set
-
TY-200S Plastic Injection Molding MachineNegotiableMOQ: 1 Set
The following materials are suitable for our products:GPPS, HIPS, SAN, ABS,LDPE, HDPE,PP, PPO, PA6, PA66, ACEAL COPOLYMER, CAB, PET, PBT,PC, PMMA, hard PVC, soft PVC,PU, EVA, PSF, Bakelite, BMC.
TY single slide-series (vertical injection machine)
Vertical clamping, vertical injection. Compact design requires less floor space. Make the take-out process easier.
Dual-cylinder extrusion system offers high extruding pressure for fast operation making this extruder your best choice for production of the thin work pieces.
Direct-pressure mold clamp allows even extrusion force, and the relatively low pressure means maximum precision and an incredibly smooth cycle of operation.
Choose a platen or a rotary plate in accordance with the type of products to be extruded, in order to achieve the best possible in input and output ratio.
This series machine offers a wide range of programmable functions including automatic inclusion, extrusion and delivery systems and other options for fully-automatic production.
Various screws are available to meet different processing needs. Optimum screw L/D ratio attains excellent plasticizing effect.
| Model | Units | TY-550S | ||
| Screw Diameter | mm | 32 | 36 | |
| Injection Pressure | Kg/cm2 | 1662 | 1313 | |
| Theoretical Shot volume | cm3 | 96 | 122 | |
| Max. Shot Weight | g/Oz | 86/3.0 | 109/3.8 | |
| Injection Rate | cm3/sec | 58 | 73 | |
| Temperature Control | ZONE | 3 | ||
| Material Hopper Capacity | L | 20 | ||
| Clamping Force | T | 55 | ||
| Opening Force | T | 8.3 | ||
| Mold Dimension | mm | 415×250 | ||
| Min Mold Height | mm | 150 | ||
| Opening Stroke | mm | 200 | ||
| Max. Open Daylight | mm | 350 | ||
| Nozzle Center Height | mm | - | ||
| Nozzle Center Distance | mm | - | ||
| Ejector Force | T | 1.3 | ||
| Ejector Stroke | mm | 40 | ||
|
|
Slide Plate Size | mm | - | |
| Slide Plate Stroke | mm | 420 | ||
| Round Set Diameter | mm | - | ||
| Max. Hydraulic Pressure | Kg/cm2 | 140 | ||
| Pump Output | L | 160 | ||
| Pump Motor Power | Kw | 5.5 | ||
| Barrel Heating Power | Kw | 4.1 | ||
| Total Wattage | Kw | 9.6 | ||
| Machine Weight | T | 2.1 | ||
| Machine Dimensions(LxWxH) | mm | 2000x900x2600 | ||
