TY-200 Vertical plastic injection molding machine

       Specification

        Model :  TY200

Units

Data

         Screw Diameter

mm

28

32

         Injection Pressure

Kg/cm²

1446

1107

     Theoretical Shot volume

cm³

65

84

   Max. Shot Weight

g/Oz

58/2.0

75/2.6

             Injection Rate

cm³/sec

50

65

             Temperature Control

ZONE

3

         Material Hopper Capacity

L

15

             Clamping Force

T

25

             Opening Force

T

6.6

         Distance Between Tie Bar

mm

360x230

         Min Mold Height

mm

100

         Opening Stroke

mm

180

     Max. Open Daylight

mm

280

         Nozzle Center Height

mm

N/A

      Nozzle Center Distance

mm

N/A

          Ejector Force

T

1.3

          Ejector Stroke

mm

40

          Slide Plate Size

mm

N/A

          Slide Plate Stroke

mm

N/A

          Round Plate Diameter

mm

N/A

          Max. Hydraulic Pressure

Kg/cm²

140

          Pump Output

L

130

          Pump Motor Power

Kw

4

          Barrel Heating Power

Kw

2.7

          Total Wattage

Kw

6.7

          Machine Weight

T

0.96

  Machine Dimension (LxWxH)

 m

1.65x1.0x2.5
