Help CenterTY-200DS Vertical Plastic Injection Machine
Related Products
-
TY-550.2R Vertical Injection Molding MachineNegotiableMOQ: 1 Set -
Vertical Plastic Injection Molding Machine 40tonNegotiableMOQ: 1 Set
-
TY-200 Vertical Plastic Injection Molding MachineNegotiableMOQ: 1 Set
-
TY-200S Plastic Injection Molding MachineNegotiableMOQ: 1 Set
-
Double Color Injection MachineUS$ 50,000 - 100,000MOQ: 1 Unit
TY-series (vertical injection machine series)
Vertical clamping, vertical injection. Compact design requires less floor space. Make the take-out process easier.
Dual-cylinder extrusion system offers high extruding pressure for fast operation making this extruder your best choice for production of the thin work pieces.
Direct-pressure mold clamp allows even extrusion force, and the relatively low pressure means maximum precision and an incredibly smooth cycle of operation.
Choose a platen or a rotary plate in accordance with the type of products to be extruded, in order to achieve the best possible in input and output ratio.
This series machine offers a wide range of programmable functions including automatic inclusion, extrusion and delivery systems and other options for fully-automatic production.
Various screws are available to meet different processing needs. Optimum screw L/D ratio attains excellent plasticizing effect.
| Model | Units | TY200DS | ||
| Screw Diameter | mm | 28 | 32 | |
| Injection Pressure | Kg/cm2 | 1446 | 1107 | |
| Theoretical Shot volume | cm3 | 65 | 84 | |
| Max. Shot Weight | g/Oz | 58/2.0 | 75/2.6 | |
| Injection Rate | cm3/sec | 50 | 65 | |
| Temperature Control | ZONE | 3 | ||
| Material Hopper Capacity | L | 15 | ||
| Clamping Force | T | 25 | ||
| Opening Force | T | 6.6 | ||
| Distance Between Tie Bar | mm | 360x230 | ||
| The Biggest Contain Mold Space | mm | 278X258 | ||
| Min Mold Height | mm | 100 | ||
| Opening Stroke | mm | 180 | ||
| Max. Open Daylight | mm | 280 | ||
| Nozzle Center Height | mm | - | ||
| Nozzle Center Distance | mm | - | ||
| Ejector Force | T | 1.3 | ||
| Ejector Stroke | mm | 40 | ||
|
|
Slide Plate Size | mm | 700x350 | |
| Slide Plate Stroke | mm | 350 | ||
| Round Set Diameter | mm | - | ||
| Max. Hydraulic Pressure | Kg/cm2 | 140 | ||
| Pump Output | L | 130 | ||
| Pump Motor Power | Kw | 4 | ||
| Barrel Heating Power | Kw | 2.7 | ||
| Total Wattage | Kw | 6.7 | ||
| Machine Weight | T | 1.5 | ||
| Machine Dimensions(LxWxH) | m | 1.8x0.9x2.7 | ||
