YH-WBS10-2R2-D1 Wilreless long range wifi transmitter 802.3at 48V PoE wireless base station access point
YH-WBS10-2R2-D
YH-WBS10-2R2-D is an carrier-class wireless Acess Point device(iEEE802.11A/B/G/N), including 2.4GHz and dual-band(2.4GHz&5.8GHz) , which based on Qualcomm Atheros platform, and accorded with industrial standards. Its protection level up to IP67, can normally work under the harsh outdoor environment; it support long distance(3.7km) communication when working with our wireless CPE device, and cloud management and control system; besides, our device can solve the problem of hidden nodes and greatly improve the download speed through Xspeed core technology.
This main functions of the WiFi device is supporting long distance communication and wide cover. For example: Broadband wireless access in countryside, scenic area, station/dock/airport/park/commercial plaza, industry zone/dormitory/school; Network bridge and so on. Base on the current network and this wifi device, the new users can access internet quickly.
Features:
- high speed rate up to 300M
- 2.4GHz frequency band
- support 16 SSID work at the same time
- support 30pcs wireless CPE device acess at the same time
- support more than 100pcs mobile or PC acess
- long distance, more than 3km
- support trestset
- waterproof IP67 and anti-thunder
Parameter:
| Item | Parameter |
| Frequency | 2.400~2.483GHz |
Transmitted Power |
27dBm(can chose) |
| Standard | IEEE 802.11 B/g/n |
| Distance | more than 3km |
| Speed rate | 300Mbps |
| Antenna | external antenna |
| Port | 1xWAN(10M/100M/1000M)RJ45,1xReset,1 Console |
| LED | 1xPower, 2xWLAN, 1xWAN, 1xStatus |
| Power |
48v (iEEE802.at)) |
Operating Temperature |
-40℃~70℃ |
Operating Humidity |
0%~100%RH(None condensation) |
Power Dissipation |
<20W |
Weight |
1.9kg |
| Size | 265mm×265mm×74mm |
Protection Standards |
IP67; Anti-thunder class:GB/T 17626.5 |
Product Pictures
