DS10-15 Full Automatic Block Making Machine sale in Libya
- 100 Set / Sets per Month
- Qingdao port
- T/T Credit Card
-
China pe200x300 smallest jaw crusher
-
Popular compound pendulum jaw crusher price
-
2016 china products stone coated steel roofing tile ,shingle steel roof tile
-
2016 china products lightweight roof tile,blue glazed roof tile
-
colored metal roofing prices,sand coated metal roofing tiles
-
roofing tiles coated with stones,roofing tiles for houses
Product Details
Condition: | New | Type: | Interlock Block Making Machine | Brick Raw Material: | Cement |
Processing: | Brick Production Line | Method: | Hydraulic Pressure | Automatic: | Yes |
Capacity: | 1800-2400 block/h, 1800-2400 block/h | Place of Origin: | Henan, China | Brand Name: | DASION |
Model Number: | DS10-15 | Power: | 36.8kw | Dimension(L*W*H): | 7200x2290x3100mm |
Certification: | ISO9001:2008 & CE | Warranty: | 12MONTHS |
Product Description
DS10-15 Full Automatic Block Making Machine sale in Libya
DS10-15 Brick Making Machinery
1. Compatible with fixed standard brick, hollow block, brick and other concrete products
2. Special design of material storage & feeding system to ensure the accuracy of material feeding
3. Adopt full program adopt PLC control and intelligent man-machine interface dialogue system
4. Reasonable distribution of vibration to increase the effect of vibrating speed.
DS10-15 Brick Making Machinery:
1. Special design of material storage & feeding system: to ensure the accuracy of material feeding; to reduce the materials uneven-density under variety of reasons
2. Multi-source vibration system: Applicable for large work platform, computer-control, hydraulic-driven and some other technologies. Adopt full-synchronous mode of vibration, vibration-hit power is adjustable;
3. Control System: Effective cooperation between digital tech and displacement sensor tech to ensure the accurate and reliable action; Suitable for application in busy complex working conditions
4. Automatic diagnosis: It prompts and alarms to solve trouble timely; Combination of remote control systems, connecting through the telephone line to achieve remote monitoring, controlling and diagnosis.
Main technical parameters of DS10-15 brick making machinery:
Parameter Name | Parameter values | |
The largest machine dimensions | 7200×2290×3100(L×W×H)(mm) | |
Rated pressure of hydraulic system | 21Mpa | |
Main vibration form | All vibration molded desk | |
Vibration frequency | 50~70Hz | |
Vibration acceleration | 10-15g | |
To adapt to the high brick | 50-200mm | |
Pallet size | Bamboo | 1070×840×40(mm) |
Molding cycle | 15s | |
Machine power | 36.8kw | |
Machine weight | 14.8t |
Main product specifications and production of each plate:
Model | Block Specifications (mm) | Forming number | Molding cycle | Capacity (pcs) |
DS10-15 | 390×190×190 (brick) | 10 | 15 | 19200 |
240×115×90 (brick) | 24 | 15 | 46080 | |
240×115×53 (standard brick) | 48 | 15 | 92160 | |
This series of 150-650 tons of products with different specifications. Brick shaped mold can be produced according to user needs. |
Production conditions: | ||
Production sites | Venues | 15-20acres |
Operate camp | 60 | |
Raw space | 300 | |
Office space | 30 | |
Other conditions | Staff | 10-15people |
Distribution | 40kw | |
Water | 10T/day |
DS series brick making machine brief introduction as following:
Model | Block Specifications(mm) | Forming Number (brick) | Molding Cycle (seconds) | Capacity (pcs) (8 hours) |
DS4-35 | 390 × 190 × 190 (hollow brick) | 4 | 35-40 | 3000-3290 |
| 240 × 115 × 90 (porous brick) | 9 | 35-40 | 7000-7400 |
| 240 × 115 × 53 (standard brick) | 21 | 35-40 | 15000-17200 |
| Bamboo pallet size: 920 × 570 × 20mm Host power: 25.5KW Machine size: 6650 × 1500 × 2650(L×W×H)mm Total weight: 4.5T | |||
DS4-15 | 390 × 190 × 190 (hollow brick) | 4 | 20-25 | 4608-5760 |
| 240 × 115 × 90 (porous brick) | 13 | 20-25 | 14950-18720 |
| 240 × 115 × 53 (standard brick) | 26 | 20-25 | 29900-37440 |
| Bamboo pallet size: 920 × 570 × 20mm Host power: 25.5KW Machine size: 6650 × 1500 × 2650(L×W×H)mm Total weight: 8.5T | |||
DS6-15 | 390 × 190 × 190 (hollow brick) | 6 | 15-25 | 7000-11520 |
| 240 × 115 × 90 (porous brick) | 12 | 15-25 | 14000-23040 |
| 240 × 115 × 53 (standard brick) | 30 | 15-25 | 34560-57600 |
| Bamboo pallet size: 800 × 700 × 25mm Host power: 29.7KW | |||
| Machine size: 8800 × 1600 × 2750(L×W×H)mm Total weight: 10.5T | |||
DS8-15 | 390 × 190 × 190 (hollow brick) | 8 | 15-20 | 11520-15360 |
| 240 × 115 × 90 (porous brick) | 21 | 15-20 | 30240-40320 |
| 240 × 115 × 53 (standard brick) | 42 | 15-20 | 60480-80640 |
| Bamboo pallet size: 920 × 850 × 40mm Host power: 36.8KW Machine size: 7200 × 2100 × 2825(L×W×H)mm Total weight: 11.8T | |||
DS10-15 | 390 × 190 × 190 (hollow brick) | 10 | 15-20 | 14400-19200 |
| 240 × 115 × 90 (porous brick) | 24 | 15-20 | 34560-46080 |
| 240 × 115 × 53 (standard brick) | 51 | 15-20 | 73440-97920 |
| Bamboo pallet size: 1070 × 840 × 40mm Host power: 36.8KW Machine size: 7200 × 2290 × 3100(L×W×H)mm Total weight: 14.8T |
