DS10-15 fully brick making machinery in dubai with high efficiency on sale

Specifications

brick making machinery
1.Full automatic with PLC
2.Smooth rotation
3.Hydraulic pressure
4. Low Noise

fully automatic  brick machine making DS10-15 in dubai with high efficiency on sale



Technical features of DS10-15:



DS10-15 Brick Making Machinery



Compatible with fixed standard brick, hollow block, brick and other concrete products;

Special design of material storage & feeding system to ensure the accuracy of material feeding;

Adopt full program adopt PLC control and intelligent man-machine interface dialogue system;

Reasonable distribution of vibration to increase the effect of vibrating speed.



DS10-15 Brick Making Machinery:



1. Special design of material storage & feeding system: to ensure the accuracy of material feeding; to reduce the materials uneven-density under variety of reasons, otherwise that will impact the charging volume; to ensure the material feeding timely, the charging accurate.

2. Multi-source vibration system: in order to adapt the design of large-scale machine. Applicable for large work platform, computer-control, hydraulic-driven and some other technologies, such as mechanical and electrical synchronization; Adopt full-synchronous mode of vibration, vibration-hit power is adjustable; The frequency can be also adjusted according to different technological requirements, feeding low-frequency, shaping high-frequency; Exciting force can be adjusted according to different raw materials to achieve the best effect of Tap.

3. Control System: Effective cooperation between digital tech and displacement sensor tech, to ensure the accurate and reliable action; Suitable for application in busy complex working conditions; System acquisition sets hundreds of prepared, technologically advanced, easy to operate.

4. Automatic diagnosis: automated random computer fault diagnosis system, prompted and alarm, in favor of trouble-solved timely; Combination of remote control systems, connecting through the telephone line, to achieve remote monitoring, controlling and diagnosis.



Brief parameters introduction as following:





Model	Block Specifications(mm)	Forming Number (brick)	Molding Cycle (seconds)	Capacity (pcs)     (8 hours)
DS4-35	390 × 190 × 190 (hollow brick)	4	35-40	3000-3290
	240 × 115 × 90 (porous brick)	9	35-40	7000-7400
	240 × 115 × 53 (standard brick)	21	35-40	15000-17200
	Bamboo pallet size: 920 × 570 × 20mm   Host power: 25.5KW Machine size: 6650 × 1500 × 2650(L×W×H)mm   Total weight: 4.5T
DS4-15	390 × 190 × 190 (hollow brick)	4	20-25	4608-5760
	240 × 115 × 90 (porous brick)	13	20-25	14950-18720
	240 × 115 × 53 (standard brick)	26	20-25	29900-37440
	Bamboo pallet size: 920 × 570 × 20mm    Host power: 25.5KW Machine size: 6650 × 1500 × 2650(L×W×H)mm   Total weight: 8.5T
DS6-15	390 × 190 × 190 (hollow brick)	6	15-25	7000-11520
	240 × 115 × 90 (porous brick)	12	15-25	14000-23040
	240 × 115 × 53 (standard brick)	30	15-25	34560-57600
	Bamboo pallet size: 800 × 700 × 25mm  Host power: 29.7KW
	Machine size: 8800 × 1600 × 2750(L×W×H)mm   Total weight: 10.5T
DS8-15	390 × 190 × 190 (hollow brick)	8	15-20	11520-15360
	240 × 115 × 90 (porous brick)	21	15-20	30240-40320
	240 × 115 × 53 (standard brick)	42	15-20	60480-80640
	Bamboo pallet size: 920 × 850 × 40mm    Host power: 36.8KW Machine size: 7200 × 2100 × 2825(L×W×H)mm   Total weight: 11.8T
DS10-15	390 × 190 × 190 (hollow brick)	10	15-20	14400-19200
	240 × 115 × 90 (porous brick)	24	15-20	34560-46080
	240 × 115 × 53 (standard brick)	51	15-20	73440-97920
	Bamboo pallet size: 1070 × 840 × 40mm     Host power: 36.8KW Machine size: 7200 × 2290 × 3100(L×W×H)mm   Total weight: 14.8T
