sticker Label die cutting machine from roll to sheet or to roll with hot stamping,hole puncher
|
Usage: 2.This machine adopts flat to flat platen,high accurate mould die cutting,label conveyor and sheeting controlled by micro-computer and touch screen ,two side of printed mark and longitudinal direction tracked by three photoelectric cell(web guide).Die cutting,rewind waste paper, sheeting can finish at one time.This machine and label slitter is necessary auxiliary machine for the flexo printing machine or continuous screen printing machine. |
Product Description
Model: |
320model |
420model |
Die cutting speed: |
20-125t/min |
20-125t/min |
Max. releasing diameter: |
450mm |
450mm |
Max. roll paper width: |
320mm |
420mm |
Max. die cutting width: |
300mm |
400mm |
Max. die cutting length: |
290mm |
400mm |
Positioning precision: |
±0.15mm |
±0.1mm |
Gross power: |
3kw |
4.5kw |
Power supply voltage: |
220v±10% |
380v |
Whole machine weight: |
about1500kg |
about2300kg |
Overall dimensions: |
2.6(L)x0.95(W)x1.4(H)(m) |
2.7(L)x1.05(W)x1.5(H)(m) |
Customer Bought This Machine,Also Have Interesting To Buy Following Machines:
- 1. Sticker Label Flexo printing machine
- 2. Label Die cutting machine to be sheet or to be roll Flat bed
- 3. Rotary Label Die Cutting Machine
- 4. Label roll to roll slitting and rewinding machine
- 5. Label Slitting and rewinding machine with die cut funcation
- 6. Label Inspection Machine
- 5. Flexo Plate Making Machine For Printing Machine
- 6. Flexo Cylinder Plate Mounter Machine
- 7. Anilox Roller Ultrasonic Cleaning Machine
- 10. Label adhesive Coating Machine
- 11. IML Label Die Cutting Machine
- 12. PS Label Printing Machine
|
Remark: Also you can choose the machine to be with inner attached material die cutting,delay roller hot stamping die cutting,laser holograph die cutting . |
