HAS VIDEO die cut flat bed machine with punching, hot-stamping ,laminating
The machine adopts accurate flatten die-cutting system, material towing is controlled by servo motor, three photocells do the web-guiding job. Die-cutting, waste removing and rewinding (or sheeting) can be finished in one process. it's suitable for die-cutting adhesive paper, dacron label and laser hologram mark. This is the ideal association equipment for flexo printing machine, silk screen printing machine, gravure printing machine and hologram mark printing machine.
Main specification:
Model |
MQ-320 |
MQ-320G |
MQ-420 |
Cutting speed |
20-125 t/min |
20-170 t/min |
20-170 t/min |
Max unwinding diameter |
450mm |
500mm |
500mm |
Max. web width |
320mm |
320mm |
420mm |
Max. mould cutting width |
300mm |
300mm |
400mm |
Max. mould cutting Length |
290mm |
300mm |
400mm |
Orientation accuracy |
±0.15mm |
±0.1mm |
±0.1mm |
Total power |
3kw |
3.5kw |
4.5kw |
Power supply: |
220v±10% |
220v±10% |
220v±10% |
Machine weight |
1500kg |
1700kg |
2300kg |
Overall dimension (L×W×H) |
2600x950x1400mm |
2600×950×1400mm |
2700x1050x1500mm |
