Help CenterAir Column Cushion Bag Making Machine For Bottles , Ink Cartridge
Related Products
-
Six Color Flexographic Printers for Plastic Bag ,film , Paper BagUS$ 1 - 1,111MOQ: 1 Set -
Flexo Printing Press MachineUS$ 9,500 - 13,000MOQ: 1 Set
-
Flexo Type Four Colors Thermal Paper Roll Printing MachineUS$ 1 - 33,000MOQ: 1 Set
-
1.5KW or 2.2 KW Inverter for Bag Making MachineUS$ 1 - 10,000MOQ: 1 Set
-
DV300-2015-T Inverter 1.5KWUS$ 1 - 10,000MOQ: 1 Set
inflatable air bubble bag making machine
NO.1 Model QZ-1200 (roll type)
Technical Parameters:
Membrane Roll Size: Max. roll width: 1250mm
Max. roll diameter:500mm
The Highest Speed of Column Pressing:
18 cycles/min.(Speed adjustable)
20 mm column- 14 columns per pressing
30 mm column- 10 columns per pressing
40 mm column- 7 columns per pressing
60 mm column- 5 columns per pressing
The Max. Width of Pressed Column: 1220mm
Column Pressing Parameters: Realized via PLC control panel for column pressing speed, welding temperature, pressing time, standards compensation, etc.
Power consumption: 15.2 kw
Air supply: 0.68MPA
Weight: 2800kg
Dimensions: 5320 X 1800 X 1680 mm
inflatable air bubble piece bag cutting machine
NO.2 QZD-800 ( bag piece by piece)
Membrane Roll Size:
Max. roll width: 1250mm
Max. roll diameter:400mm
Speed : 24-35 pcs/min.
Max. Bag length: <900mm
Max. Bag width: <750mm
Bag Making Parameters: Realized by PCL control panel for setting pressing time, pressing temperature, standards compensation, roll-unwinding, automatic variation correction system
Power consumption: 2.7 kw
Air supply: 0.65MPA
Weight: 1800kg
Dimensions: 4400 X 2400 X 1480 mm
wooden box,60 days seaworthy
