Product Features:
- Modularization, Tri-proof and low power consumption
- 2.4G Wifi transmission
- Support 802.11 b/n/g
- Support TCP/IP/UDP internet protocol
- Support STA/AP/AP+STA working module
- Support Router/ bridge pattern internet construction
- Support up to 32 TCP connection
- Stable, long distance transmission and power can be adjustable
- IP NLOS transmission
- Single carrier frequency transmits up to 4 users’ simultaneous two-way data transmission
- Support 64/128 bit WEP, WPA-PSK, WPA2-PSK
Parameters:
Item |
Description |
Working Frequency |
2.412GHz-2.484GHz
|
Transmission Speed |
IEEE 802.11n:150Mbps IEEE 802.11g:54/48/36/24/18/12/9/6Mbps adjustable IEEE 802.11b :11/5.5/2/1Mbps adjustable |
No. of Channels |
13 |
Modulation Method |
802.11b:DSSS (CCK, DQPSK, DBPSK) 802.11g/n:OFDM (BPSK, QPSK, 16QAM, 64QAM)
|
FEC(forward error correction) |
13 |
Transmission Power Rate(output) |
≥30dBm |
Band Flatness |
≤ ±0.5dB |
|
Spurious Spectrum |
≤ -36dBm |
|
Third-order Inter Modulation |
≤ -36dBC |
Receiving Sensitivity |
135M:-75dBm@10% PER; 54M:-78dBm@10% PER 11M:-95dBm@8% PER; 1M:-100dBm@8% PER;(Typical Index) |
MER |
≥ 36dB |
Transmission Distance |
Up to 200M indoor and 500M outdoor |
Anti-Frequency Interference |
≥ 40dB |
Video Encoding |
MPEG2 4:2:0 |
Video Input |
CVBS |
Audio Decoding |
G.711 |
Communication Method |
Support bidirectional full duplex communication |
Transmission Bandwidth |
Maximum 150Mbps |
Internet Protocol |
IP/TCP,UDP,HTTP,SMTP or others |
Operating Temperature |
-20 ~ +70°C |
Power Supply |
DC12V/2A /7.2V 1400mA Lithium battery |
Consumption |
≤10W |
Dimensions |
? |
Weight |
≤5Kg |
Power Interface |
1.0mm DC-Jack pin |
Video Input |
AV: 3.5mm Interface to analogue, Camera: 2.5 Interface to IPC |
RF Antenna Interface |
SMA |
Audio Input |
3.5mm CRV Pin |
Power Switch |
The auto-lockable Switch with lamp |
|
|
Our service:
1. we accept all terms of trade
2. we provide professional system design and construction
3. Lifelong maintenance
4. 24-hour technical support
5. we have TEN years experience in wireless transmission area, we are professional factory, so we can provide you:high quality products,better product pre-sales and after-sales service,attractive prices,shorter delivery.
