Help Center4G Dome Camera PTZ for Wireless Video Transmission and Receiving
Related Products
-
3G 4G Wifi PTZ Wireless Video Transmitter With CMOS 2.0M CameraNegotiableMOQ: 1 Unit -
2.4G Digital Video Wireless Transmitter and ReceiverNegotiableMOQ: 1 Pair
-
High Gain 5.2 5.8G 32dBi Double Polarization Parabolic AntennaNegotiableMOQ: 1 Set
-
PROMPT GOODS! Broadcasting NLOS Cofdm Wireless Video TransmitterUS$ 1 - 10,000MOQ: 1 Piece
-
RF Receiver Board COFDM Hdmi to rf ModulatorUS$ 1 - 5,000MOQ: 1 Piece
LinkAV wireless transmission system advantages:
- Long range transmission distance
- Real-time transmission systems
- Delay time very short less than 500ms
- Perfect image quality, brighter colors and image smoothness.
Product Parameters:
Picture Process |
Mega Pixels CMOS |
Resolution |
1080P/30F |
Minimal Illumination |
Infrared on 0 Lux |
Power |
f=3.6mm, 10 times zoom, Anti infrared microscope |
IR_CUT |
Can be switched to infrared or color filter |
The Horizontal Angle |
355° |
Vertical Angle |
>=90° |
Presets |
6 |
Infrared Light Control |
Automatic control by means of photosensitive resistance, but also can be manually controlled |
Irradiation Distance |
Over 10 Meters |
Main Stream |
1080P(1920*1080)/1280*720/640*480 |
Second Stream |
640*360/320*180 |
Video Compression |
H.264/JPEG |
Maximal FPS |
30FPS |
Data Rate |
1.024Mbps ~ 4.096Mbps |
Sub Data Rate |
128 kbps~1024kbps |
Picture Orientation |
Mirror/Inversion |
Character Overlay |
Support |
Audio Compression |
G.711/G.726 |
Basic Protocol |
TCP/IP,HTTP,SMTP,RTSP,FTP,DHCP,DDNS,UPNP,NTP |
Other Protocols |
802.11b/g/n |
|
Mobile App |
4G |
Support | |
Video Control |
Support |
Two-way Voice Transmission |
Support |
Storage |
SD card (capturing and video) |
SD Card Preview |
Can remotely control SD card, can also download |
Motion Detection |
Support up to 4 motion detection zones |
Alerting Notification |
Email/FTP/SD Card/Outside Alerting/Send notifications to the alerting server |
User Setup |
Third Grade User Permission |
Date/Time Setup |
Support |
|
Upgrade
|
Can be upgraded by Internet
|
Ethernet Port |
10Base-T/100base-TX |
Storage Port |
SD Card Slot |
Alerting Input |
2 Channels |
Alerting Output |
1 Channel |
Audio Input |
1 Audio Input Hole |
Audio Output |
1 Audio Output Hole |
Control Port |
RS485 |
Antenna Port |
4G Antenna Port |
|
Wifi Antenna Port |
Power Supply |
DC 12V |
Power Consumption |
<8W |
Work Temperature |
-20℃~ 60℃ |
Humidity |
10% ~ 80% Not Frozen |
