Specifications
suitable for printing such packing materials as polyethylene, polypropylene bag, cellophane and roll paper, etc.
Application: Introduce sensitization resin as flexible printing plate, suitable for printing such packing materials as polyethylene, polypropylene bag, cellophane and roll paper, etc. It is a kind of ideal printing equipment for producing paper packing bag for food, supermarket handbag, vest bag and clothes bag, etc.
Main Technical Variables:
Model of Machine |
YT-4600 |
YT-4800 |
YT-41000 |
Max.Width of Printing Material |
600mm |
800mm |
1000mm |
Max.Printing With |
560mm |
760mm |
960mm |
Length Range of Printed Product |
191-914mm |
191-914mm |
191-914mm |
Max.Diameter of Roll Material |
φ450mm |
φ450mm |
φ450mm |
Printing Speed |
5~50m/min |
5~50m/min |
5~50m/min |
Thickness of plate(Including Two-sides Glue Paper) |
2.38mm |
2.38mm |
2.38mm |
Total Power |
10.87kw |
12.5kw |
14.37kw |
Weight of Machine |
3000kg |
3500kg |
4000kg |
Overall Dimensions |
4200*1600*2400mm |
4200*1800*2400mm |
4200*2000*2400mm |
